Comparing catgraph modality networks with MCA and bipartite approaches
Source:vignettes/comparison.Rmd
comparison.RmdWhy this vignette
catgraph’s modality layer is one of several established
traditions for analysing the structure of categorical data. This
vignette runs the modality-level workflow on the bundled
survey_health dataset alongside three alternative methods,
so readers can see directly what each method says — and, crucially,
where catgraph adds information and where it should
not be overclaimed. A final section introduces
joint_balance(), the high-level cross-group diagnostic
shipped in v0.8.0.
The methods compared:
-
catgraphmodality network — chi-square / phi-filtered co-association graph on modalities. Scope: which category levels significantly co-associate across variables. - Multiple Correspondence Analysis (MCA) — geometric approach. Scope: low-dimensional embedding of modalities in a continuous space based on chi-square distances between row and column profiles.
- Bipartite respondent–modality network — two-mode incidence graph. Scope: the raw unprojected endorsement structure, before any statistical filter.
- Naive co-occurrence projection — the bipartite graph projected onto its modality partition, with edges weighted by raw count of shared respondents. Scope: which modality pairs are most frequently endorsed together, without adjustment for base rates.
All four are descriptive methods. None is a substitute for the others; each answers a different question about the same categorical data.
Setup
library(catgraph)
library(igraph)
data(survey_health)
str(survey_health)
#> 'data.frame': 600 obs. of 8 variables:
#> $ sex : Factor w/ 2 levels "female","male": 2 1 2 2 1 2 1 1 2 1 ...
#> $ age_group : Factor w/ 3 levels "18-34","35-54",..: 3 3 2 1 2 1 3 2 3 3 ...
#> $ smoking_status : Factor w/ 3 levels "never","former",..: 2 2 3 3 2 3 1 2 1 3 ...
#> $ lung_disease : Factor w/ 2 levels "no","yes": NA 2 1 1 1 1 1 1 1 1 ...
#> $ exercise_freq : Factor w/ 3 levels "low","moderate",..: 1 2 2 1 2 2 1 1 2 2 ...
#> $ bmi_category : Factor w/ 4 levels "underweight",..: NA 2 3 3 2 3 4 4 3 2 ...
#> $ diet_quality : Factor w/ 3 levels "poor","fair",..: 2 2 NA 1 3 3 3 3 1 1 ...
#> $ health_insurance: Factor w/ 2 levels "no","yes": 2 1 2 2 1 1 2 2 2 2 ...survey_health is a synthetic dataset with 600
respondents, eight categorical variables, and known designed-in
association structure. See ?survey_health for details.
Method 1 — catgraph modality network
mg <- build_modality_graph(survey_health)
mg <- prune_modality_edges(mg, min_weight = 0.10, max_p = 0.05)
set.seed(1)
mg <- cluster_modalities(mg, method = "louvain")
mg
#> $graph
#> IGRAPH 8bb773c UNW- 22 38 --
#> + attr: name (v/c), variable (v/c), modality (v/c), cluster (v/n),
#> | weight (e/n), phi_signed (e/n), p_value (e/n), std_resid (e/n)
#> + edges from 8bb773c (vertex names):
#> [1] sex=female --age_group=35-54
#> [2] sex=male --age_group=35-54
#> [3] sex=female --age_group=55+
#> [4] sex=male --age_group=55+
#> [5] age_group=18-34 --smoking_status=never
#> [6] age_group=55+ --smoking_status=never
#> [7] age_group=18-34 --smoking_status=former
#> + ... omitted several edges
#>
#> $modalities
#> node variable modality
#> 1 sex=female sex female
#> 2 sex=male sex male
#> 3 age_group=18-34 age_group 18-34
#> 4 age_group=35-54 age_group 35-54
#> 5 age_group=55+ age_group 55+
#> 6 smoking_status=never smoking_status never
#> 7 smoking_status=former smoking_status former
#> 8 smoking_status=current smoking_status current
#> 9 lung_disease=no lung_disease no
#> 10 lung_disease=yes lung_disease yes
#> 11 exercise_freq=low exercise_freq low
#> 12 exercise_freq=moderate exercise_freq moderate
#> 13 exercise_freq=high exercise_freq high
#> 14 bmi_category=underweight bmi_category underweight
#> 15 bmi_category=normal bmi_category normal
#> 16 bmi_category=overweight bmi_category overweight
#> 17 bmi_category=obese bmi_category obese
#> 18 diet_quality=poor diet_quality poor
#> 19 diet_quality=fair diet_quality fair
#> 20 diet_quality=good diet_quality good
#> 21 health_insurance=no health_insurance no
#> 22 health_insurance=yes health_insurance yes
#>
#> $indicator_matrix
#> sex=female sex=male age_group=18-34 age_group=35-54 age_group=55+
#> [1,] 1 0 0 0 1
#> [2,] 0 1 1 0 0
#> [3,] 1 0 0 1 0
#> [4,] 0 1 1 0 0
#> [5,] 1 0 0 0 1
#> [6,] 1 0 0 1 0
#> [7,] 0 1 0 0 1
#> [8,] 1 0 0 0 1
#> [9,] 0 1 1 0 0
#> [10,] 1 0 1 0 0
#> [11,] 1 0 0 0 1
#> [12,] 0 1 0 0 1
#> [13,] 1 0 1 0 0
#> [14,] 0 1 0 1 0
#> [15,] 1 0 0 0 1
#> [16,] 1 0 1 0 0
#> [17,] 0 1 0 1 0
#> [18,] 0 1 0 1 0
#> [19,] 0 1 0 1 0
#> [20,] 1 0 0 0 1
#> [21,] 0 1 0 1 0
#> [22,] 0 1 0 0 1
#> [23,] 1 0 0 0 1
#> [24,] 1 0 1 0 0
#> [25,] 1 0 0 1 0
#> [26,] 1 0 1 0 0
#> [27,] 0 1 0 1 0
#> [28,] 0 1 1 0 0
#> [29,] 0 1 0 0 1
#> [30,] 0 1 1 0 0
#> [31,] 1 0 0 1 0
#> [32,] 0 1 0 1 0
#> [33,] 0 1 0 1 0
#> [34,] 0 1 1 0 0
#> [35,] 1 0 1 0 0
#> [36,] 0 1 1 0 0
#> [37,] 1 0 0 1 0
#> [38,] 1 0 0 1 0
#> [39,] 0 1 0 0 1
#> [40,] 0 1 1 0 0
#> [41,] 1 0 1 0 0
#> [42,] 0 1 0 1 0
#> [43,] 1 0 0 1 0
#> [44,] 1 0 1 0 0
#> [45,] 0 1 0 0 1
#> [46,] 0 1 0 0 1
#> [47,] 1 0 0 1 0
#> [48,] 1 0 0 1 0
#> [49,] 1 0 0 0 1
#> [50,] 1 0 1 0 0
#> [51,] 1 0 0 1 0
#> [52,] 0 1 1 0 0
#> [53,] 1 0 0 0 1
#> [54,] 0 1 0 1 0
#> [55,] 0 1 0 1 0
#> [56,] 0 1 1 0 0
#> [57,] 1 0 0 0 1
#> [58,] 1 0 0 1 0
#> [59,] 0 1 0 1 0
#> [60,] 0 1 0 0 1
#> [61,] 0 1 0 1 0
#> [62,] 1 0 1 0 0
#> [63,] 1 0 1 0 0
#> [64,] 1 0 0 0 1
#> [65,] 1 0 1 0 0
#> [66,] 0 1 1 0 0
#> [67,] 1 0 1 0 0
#> [68,] 0 1 1 0 0
#> [69,] 1 0 0 1 0
#> [70,] 1 0 0 0 1
#> [71,] 0 1 0 1 0
#> [72,] 0 1 0 0 1
#> [73,] 0 1 0 1 0
#> [74,] 0 1 0 1 0
#> [75,] 1 0 1 0 0
#> [76,] 0 1 1 0 0
#> [77,] 1 0 0 1 0
#> [78,] 0 1 0 1 0
#> [79,] 0 1 0 0 1
#> [80,] 1 0 0 1 0
#> [81,] 0 1 1 0 0
#> [82,] 1 0 0 0 1
#> [83,] 0 1 0 1 0
#> [84,] 1 0 0 1 0
#> [85,] 1 0 1 0 0
#> [86,] 1 0 0 0 1
#> [87,] 0 1 0 0 1
#> [88,] 1 0 0 1 0
#> [89,] 1 0 0 1 0
#> [90,] 1 0 1 0 0
#> [91,] 1 0 0 1 0
#> [92,] 1 0 0 0 1
#> [93,] 0 1 0 1 0
#> [94,] 0 1 1 0 0
#> [95,] 0 1 1 0 0
#> [96,] 1 0 0 1 0
#> [97,] 1 0 0 1 0
#> [98,] 1 0 1 0 0
#> [99,] 1 0 0 0 1
#> [100,] 0 1 1 0 0
#> [101,] 0 1 0 1 0
#> [102,] 0 1 1 0 0
#> [103,] 1 0 0 1 0
#> [104,] 0 1 0 1 0
#> [105,] 0 1 1 0 0
#> [106,] 1 0 1 0 0
#> [107,] 1 0 1 0 0
#> [108,] 1 0 1 0 0
#> [109,] 1 0 0 1 0
#> [110,] 0 1 0 1 0
#> [111,] 1 0 1 0 0
#> [112,] 1 0 0 0 1
#> [113,] 1 0 1 0 0
#> [114,] 1 0 1 0 0
#> [115,] 0 1 0 0 1
#> [116,] 0 1 1 0 0
#> [117,] 0 1 0 0 1
#> [118,] 1 0 1 0 0
#> [119,] 0 1 1 0 0
#> [120,] 0 1 0 0 1
#> [121,] 0 1 1 0 0
#> [122,] 0 1 0 1 0
#> [123,] 1 0 0 0 1
#> [124,] 1 0 1 0 0
#> [125,] 1 0 1 0 0
#> [126,] 0 1 0 0 1
#> [127,] 0 1 0 0 1
#> [128,] 1 0 1 0 0
#> [129,] 1 0 0 0 1
#> [130,] 0 1 0 1 0
#> [131,] 1 0 0 0 1
#> [132,] 0 1 0 1 0
#> [133,] 0 1 0 1 0
#> [134,] 0 1 1 0 0
#> [135,] 0 1 0 0 1
#> [136,] 1 0 0 1 0
#> [137,] 1 0 1 0 0
#> [138,] 1 0 1 0 0
#> [139,] 1 0 0 1 0
#> [140,] 1 0 0 1 0
#> [141,] 1 0 1 0 0
#> [142,] 1 0 1 0 0
#> [143,] 1 0 0 1 0
#> [144,] 1 0 0 1 0
#> [145,] 0 1 1 0 0
#> [146,] 1 0 0 1 0
#> [147,] 0 1 1 0 0
#> [148,] 1 0 1 0 0
#> [149,] 0 1 0 1 0
#> [150,] 1 0 1 0 0
#> [151,] 1 0 0 0 1
#> [152,] 0 1 0 1 0
#> [153,] 0 1 0 1 0
#> [154,] 1 0 1 0 0
#> [155,] 1 0 1 0 0
#> [156,] 0 1 1 0 0
#> [157,] 1 0 1 0 0
#> [158,] 0 1 1 0 0
#> [159,] 1 0 0 0 1
#> [160,] 1 0 0 0 1
#> [161,] 1 0 0 1 0
#> [162,] 1 0 0 0 1
#> [163,] 0 1 0 1 0
#> [164,] 1 0 0 0 1
#> [165,] 1 0 0 1 0
#> [166,] 1 0 1 0 0
#> [167,] 1 0 1 0 0
#> [168,] 0 1 0 1 0
#> [169,] 1 0 0 1 0
#> [170,] 0 1 0 1 0
#> [171,] 1 0 0 1 0
#> [172,] 1 0 1 0 0
#> [173,] 0 1 1 0 0
#> [174,] 1 0 0 1 0
#> [175,] 1 0 0 1 0
#> [176,] 1 0 0 0 1
#> [177,] 1 0 0 0 1
#> [178,] 1 0 1 0 0
#> [179,] 0 1 0 1 0
#> [180,] 1 0 0 0 1
#> [181,] 0 1 1 0 0
#> [182,] 1 0 0 1 0
#> [183,] 1 0 0 0 1
#> [184,] 1 0 0 1 0
#> [185,] 1 0 0 1 0
#> [186,] 1 0 1 0 0
#> [187,] 1 0 0 0 1
#> [188,] 1 0 1 0 0
#> [189,] 1 0 0 0 1
#> [190,] 1 0 0 0 1
#> [191,] 0 1 0 0 1
#> [192,] 0 1 0 1 0
#> [193,] 0 1 1 0 0
#> [194,] 1 0 0 1 0
#> [195,] 1 0 1 0 0
#> [196,] 0 1 0 0 1
#> [197,] 0 1 0 1 0
#> [198,] 1 0 0 0 1
#> [199,] 1 0 0 0 1
#> [200,] 1 0 0 1 0
#> [201,] 1 0 0 1 0
#> [202,] 1 0 1 0 0
#> [203,] 0 1 0 1 0
#> [204,] 0 1 0 0 1
#> [205,] 0 1 1 0 0
#> [206,] 1 0 1 0 0
#> [207,] 0 1 0 1 0
#> [208,] 1 0 1 0 0
#> [209,] 0 1 0 1 0
#> [210,] 0 1 1 0 0
#> [211,] 0 1 0 0 1
#> [212,] 1 0 0 1 0
#> [213,] 0 1 1 0 0
#> [214,] 1 0 1 0 0
#> [215,] 1 0 0 1 0
#> [216,] 0 1 1 0 0
#> [217,] 0 1 1 0 0
#> [218,] 0 1 0 1 0
#> [219,] 1 0 1 0 0
#> [220,] 0 1 0 1 0
#> [221,] 1 0 0 0 1
#> [222,] 0 1 0 0 1
#> [223,] 1 0 0 0 1
#> [224,] 1 0 0 1 0
#> [225,] 0 1 1 0 0
#> [226,] 1 0 0 1 0
#> [227,] 1 0 0 0 1
#> [228,] 1 0 1 0 0
#> [229,] 1 0 0 1 0
#> [230,] 0 1 0 1 0
#> [231,] 0 1 0 0 1
#> [232,] 1 0 0 1 0
#> [233,] 0 1 0 0 1
#> [234,] 1 0 1 0 0
#> [235,] 0 1 0 1 0
#> [236,] 1 0 1 0 0
#> [237,] 1 0 1 0 0
#> [238,] 0 1 0 1 0
#> [239,] 0 1 1 0 0
#> [240,] 1 0 0 0 1
#> [241,] 0 1 0 1 0
#> [242,] 0 1 0 1 0
#> [243,] 0 1 0 1 0
#> [244,] 1 0 0 0 1
#> [245,] 0 1 0 1 0
#> [246,] 0 1 1 0 0
#> [247,] 0 1 0 1 0
#> [248,] 1 0 0 1 0
#> [249,] 1 0 0 1 0
#> [250,] 0 1 1 0 0
#> [251,] 0 1 1 0 0
#> [252,] 1 0 1 0 0
#> [253,] 0 1 0 1 0
#> [254,] 0 1 0 1 0
#> [255,] 0 1 1 0 0
#> [256,] 0 1 0 1 0
#> [257,] 0 1 0 1 0
#> [258,] 0 1 1 0 0
#> [259,] 1 0 1 0 0
#> [260,] 0 1 1 0 0
#> [261,] 0 1 0 1 0
#> [262,] 1 0 0 0 1
#> [263,] 1 0 1 0 0
#> [264,] 0 1 1 0 0
#> [265,] 1 0 0 1 0
#> [266,] 1 0 0 1 0
#> [267,] 1 0 1 0 0
#> [268,] 1 0 0 0 1
#> [269,] 1 0 1 0 0
#> [270,] 0 1 1 0 0
#> [271,] 0 1 1 0 0
#> [272,] 0 1 1 0 0
#> [273,] 1 0 1 0 0
#> [274,] 0 1 1 0 0
#> [275,] 1 0 1 0 0
#> [276,] 0 1 0 0 1
#> [277,] 0 1 1 0 0
#> [278,] 0 1 0 1 0
#> [279,] 0 1 1 0 0
#> [280,] 0 1 0 1 0
#> [281,] 1 0 0 0 1
#> [282,] 1 0 0 1 0
#> [283,] 0 1 1 0 0
#> [284,] 1 0 0 1 0
#> [285,] 1 0 1 0 0
#> [286,] 1 0 0 1 0
#> [287,] 0 1 1 0 0
#> [288,] 1 0 1 0 0
#> [289,] 0 1 0 1 0
#> [290,] 1 0 1 0 0
#> [291,] 1 0 1 0 0
#> [292,] 0 1 0 1 0
#> [293,] 0 1 1 0 0
#> [294,] 0 1 0 1 0
#> [295,] 0 1 0 1 0
#> [296,] 1 0 1 0 0
#> [297,] 0 1 0 1 0
#> [298,] 0 1 0 1 0
#> [299,] 0 1 0 1 0
#> [300,] 0 1 0 1 0
#> [301,] 0 1 0 1 0
#> [302,] 1 0 1 0 0
#> [303,] 0 1 0 1 0
#> [304,] 1 0 0 1 0
#> [305,] 0 1 0 1 0
#> [306,] 1 0 0 1 0
#> [307,] 1 0 0 0 1
#> [308,] 0 1 0 0 1
#> [309,] 0 1 0 0 1
#> [310,] 1 0 0 1 0
#> [311,] 1 0 0 0 1
#> [312,] 0 1 0 0 1
#> [313,] 0 1 0 0 1
#> [314,] 1 0 0 0 1
#> [315,] 0 1 0 1 0
#> [316,] 1 0 0 1 0
#> [317,] 1 0 0 0 1
#> [318,] 1 0 1 0 0
#> [319,] 1 0 1 0 0
#> [320,] 1 0 0 0 1
#> [321,] 0 1 0 0 1
#> [322,] 1 0 0 0 1
#> [323,] 1 0 1 0 0
#> [324,] 1 0 0 1 0
#> [325,] 1 0 0 0 1
#> [326,] 1 0 1 0 0
#> [327,] 0 1 0 0 1
#> [328,] 0 1 0 1 0
#> [329,] 0 1 0 1 0
#> [330,] 1 0 0 0 1
#> [331,] 1 0 1 0 0
#> [332,] 0 1 0 0 1
#> [333,] 0 1 0 0 1
#> [334,] 0 1 1 0 0
#> [335,] 0 1 0 1 0
#> [336,] 0 1 1 0 0
#> [337,] 1 0 0 0 1
#> [338,] 0 1 1 0 0
#> [339,] 1 0 1 0 0
#> [340,] 1 0 1 0 0
#> [341,] 0 1 1 0 0
#> [342,] 0 1 0 1 0
#> [343,] 1 0 0 1 0
#> [344,] 0 1 0 1 0
#> [345,] 1 0 0 0 1
#> [346,] 1 0 0 1 0
#> [347,] 0 1 0 1 0
#> [348,] 1 0 1 0 0
#> [349,] 0 1 1 0 0
#> [350,] 0 1 1 0 0
#> [351,] 1 0 0 0 1
#> [352,] 0 1 0 1 0
#> [353,] 1 0 1 0 0
#> [354,] 0 1 1 0 0
#> [355,] 1 0 0 1 0
#> [356,] 0 1 1 0 0
#> [357,] 1 0 1 0 0
#> [358,] 0 1 0 1 0
#> [359,] 0 1 1 0 0
#> [360,] 1 0 0 0 1
#> [361,] 0 1 1 0 0
#> [362,] 1 0 0 1 0
#> [363,] 0 1 0 1 0
#> [364,] 0 1 0 1 0
#> [365,] 0 1 1 0 0
#> [366,] 0 1 0 0 1
#> [367,] 1 0 0 0 1
#> [368,] 0 1 1 0 0
#> [369,] 1 0 0 1 0
#> [370,] 1 0 1 0 0
#> [371,] 0 1 0 0 1
#> [372,] 0 1 0 0 1
#> [373,] 1 0 0 0 1
#> [374,] 1 0 0 1 0
#> [375,] 0 1 1 0 0
#> [376,] 1 0 0 0 1
#> [377,] 0 1 0 1 0
#> [378,] 1 0 0 1 0
#> [379,] 0 1 1 0 0
#> [380,] 0 1 0 1 0
#> [381,] 0 1 1 0 0
#> [382,] 0 1 0 0 1
#> [383,] 0 1 1 0 0
#> [384,] 0 1 0 1 0
#> [385,] 0 1 0 0 1
#> [386,] 0 1 1 0 0
#> [387,] 1 0 1 0 0
#> [388,] 1 0 1 0 0
#> [389,] 0 1 0 1 0
#> [390,] 1 0 0 1 0
#> [391,] 1 0 1 0 0
#> [392,] 1 0 0 1 0
#> [393,] 0 1 0 1 0
#> [394,] 1 0 1 0 0
#> [395,] 1 0 1 0 0
#> [396,] 0 1 0 1 0
#> [397,] 0 1 0 1 0
#> [398,] 0 1 0 1 0
#> [399,] 0 1 0 1 0
#> [400,] 1 0 0 0 1
#> [401,] 0 1 1 0 0
#> smoking_status=never smoking_status=former smoking_status=current
#> [1,] 0 1 0
#> [2,] 0 0 1
#> [3,] 0 1 0
#> [4,] 0 0 1
#> [5,] 1 0 0
#> [6,] 0 1 0
#> [7,] 1 0 0
#> [8,] 0 0 1
#> [9,] 1 0 0
#> [10,] 1 0 0
#> [11,] 0 1 0
#> [12,] 0 1 0
#> [13,] 1 0 0
#> [14,] 0 1 0
#> [15,] 0 1 0
#> [16,] 1 0 0
#> [17,] 0 0 1
#> [18,] 0 1 0
#> [19,] 1 0 0
#> [20,] 0 1 0
#> [21,] 0 0 1
#> [22,] 1 0 0
#> [23,] 1 0 0
#> [24,] 0 1 0
#> [25,] 1 0 0
#> [26,] 0 0 1
#> [27,] 1 0 0
#> [28,] 0 1 0
#> [29,] 1 0 0
#> [30,] 1 0 0
#> [31,] 0 1 0
#> [32,] 0 1 0
#> [33,] 1 0 0
#> [34,] 1 0 0
#> [35,] 1 0 0
#> [36,] 1 0 0
#> [37,] 0 1 0
#> [38,] 1 0 0
#> [39,] 0 1 0
#> [40,] 1 0 0
#> [41,] 0 0 1
#> [42,] 0 1 0
#> [43,] 1 0 0
#> [44,] 1 0 0
#> [45,] 0 1 0
#> [46,] 1 0 0
#> [47,] 1 0 0
#> [48,] 1 0 0
#> [49,] 0 1 0
#> [50,] 1 0 0
#> [51,] 1 0 0
#> [52,] 1 0 0
#> [53,] 0 1 0
#> [54,] 0 1 0
#> [55,] 1 0 0
#> [56,] 1 0 0
#> [57,] 0 1 0
#> [58,] 0 0 1
#> [59,] 0 0 1
#> [60,] 0 1 0
#> [61,] 1 0 0
#> [62,] 0 0 1
#> [63,] 0 0 1
#> [64,] 1 0 0
#> [65,] 1 0 0
#> [66,] 0 0 1
#> [67,] 0 0 1
#> [68,] 0 0 1
#> [69,] 0 0 1
#> [70,] 1 0 0
#> [71,] 0 0 1
#> [72,] 0 1 0
#> [73,] 0 0 1
#> [74,] 1 0 0
#> [75,] 1 0 0
#> [76,] 0 1 0
#> [77,] 0 0 1
#> [78,] 1 0 0
#> [79,] 0 1 0
#> [80,] 0 0 1
#> [81,] 1 0 0
#> [82,] 0 1 0
#> [83,] 0 1 0
#> [84,] 0 0 1
#> [85,] 0 0 1
#> [86,] 0 1 0
#> [87,] 0 1 0
#> [88,] 0 0 1
#> [89,] 0 1 0
#> [90,] 1 0 0
#> [91,] 1 0 0
#> [92,] 0 1 0
#> [93,] 0 0 1
#> [94,] 1 0 0
#> [95,] 1 0 0
#> [96,] 0 1 0
#> [97,] 0 1 0
#> [98,] 1 0 0
#> [99,] 0 1 0
#> [100,] 0 0 1
#> [101,] 1 0 0
#> [102,] 1 0 0
#> [103,] 1 0 0
#> [104,] 1 0 0
#> [105,] 1 0 0
#> [106,] 1 0 0
#> [107,] 0 0 1
#> [108,] 1 0 0
#> [109,] 1 0 0
#> [110,] 0 1 0
#> [111,] 0 1 0
#> [112,] 1 0 0
#> [113,] 1 0 0
#> [114,] 1 0 0
#> [115,] 1 0 0
#> [116,] 0 0 1
#> [117,] 0 0 1
#> [118,] 0 1 0
#> [119,] 1 0 0
#> [120,] 1 0 0
#> [121,] 1 0 0
#> [122,] 1 0 0
#> [123,] 1 0 0
#> [124,] 1 0 0
#> [125,] 1 0 0
#> [126,] 0 1 0
#> [127,] 0 0 1
#> [128,] 1 0 0
#> [129,] 0 1 0
#> [130,] 0 0 1
#> [131,] 1 0 0
#> [132,] 1 0 0
#> [133,] 0 0 1
#> [134,] 1 0 0
#> [135,] 1 0 0
#> [136,] 0 1 0
#> [137,] 1 0 0
#> [138,] 1 0 0
#> [139,] 1 0 0
#> [140,] 0 1 0
#> [141,] 0 1 0
#> [142,] 0 0 1
#> [143,] 0 0 1
#> [144,] 1 0 0
#> [145,] 1 0 0
#> [146,] 1 0 0
#> [147,] 1 0 0
#> [148,] 0 0 1
#> [149,] 1 0 0
#> [150,] 1 0 0
#> [151,] 0 1 0
#> [152,] 0 1 0
#> [153,] 1 0 0
#> [154,] 1 0 0
#> [155,] 1 0 0
#> [156,] 1 0 0
#> [157,] 1 0 0
#> [158,] 0 0 1
#> [159,] 1 0 0
#> [160,] 0 1 0
#> [161,] 0 1 0
#> [162,] 1 0 0
#> [163,] 1 0 0
#> [164,] 0 0 1
#> [165,] 1 0 0
#> [166,] 1 0 0
#> [167,] 0 0 1
#> [168,] 1 0 0
#> [169,] 1 0 0
#> [170,] 1 0 0
#> [171,] 0 1 0
#> [172,] 0 0 1
#> [173,] 0 0 1
#> [174,] 0 0 1
#> [175,] 1 0 0
#> [176,] 0 1 0
#> [177,] 1 0 0
#> [178,] 1 0 0
#> [179,] 1 0 0
#> [180,] 0 1 0
#> [181,] 0 0 1
#> [182,] 0 0 1
#> [183,] 1 0 0
#> [184,] 1 0 0
#> [185,] 0 0 1
#> [186,] 0 1 0
#> [187,] 0 0 1
#> [188,] 1 0 0
#> [189,] 0 1 0
#> [190,] 0 1 0
#> [191,] 0 0 1
#> [192,] 0 1 0
#> [193,] 0 0 1
#> [194,] 0 1 0
#> [195,] 1 0 0
#> [196,] 0 1 0
#> [197,] 1 0 0
#> [198,] 0 1 0
#> [199,] 0 0 1
#> [200,] 0 1 0
#> [201,] 0 1 0
#> [202,] 1 0 0
#> [203,] 1 0 0
#> [204,] 1 0 0
#> [205,] 1 0 0
#> [206,] 0 0 1
#> [207,] 1 0 0
#> [208,] 1 0 0
#> [209,] 0 1 0
#> [210,] 0 0 1
#> [211,] 1 0 0
#> [212,] 1 0 0
#> [213,] 0 1 0
#> [214,] 1 0 0
#> [215,] 1 0 0
#> [216,] 1 0 0
#> [217,] 1 0 0
#> [218,] 0 0 1
#> [219,] 0 1 0
#> [220,] 0 1 0
#> [221,] 0 0 1
#> [222,] 1 0 0
#> [223,] 0 1 0
#> [224,] 1 0 0
#> [225,] 1 0 0
#> [226,] 1 0 0
#> [227,] 1 0 0
#> [228,] 0 1 0
#> [229,] 1 0 0
#> [230,] 0 0 1
#> [231,] 0 0 1
#> [232,] 0 1 0
#> [233,] 0 1 0
#> [234,] 1 0 0
#> [235,] 0 0 1
#> [236,] 1 0 0
#> [237,] 1 0 0
#> [238,] 0 0 1
#> [239,] 1 0 0
#> [240,] 1 0 0
#> [241,] 0 0 1
#> [242,] 1 0 0
#> [243,] 1 0 0
#> [244,] 0 1 0
#> [245,] 0 0 1
#> [246,] 0 0 1
#> [247,] 0 0 1
#> [248,] 0 1 0
#> [249,] 0 1 0
#> [250,] 1 0 0
#> [251,] 0 0 1
#> [252,] 1 0 0
#> [253,] 0 1 0
#> [254,] 0 1 0
#> [255,] 1 0 0
#> [256,] 0 0 1
#> [257,] 1 0 0
#> [258,] 0 1 0
#> [259,] 1 0 0
#> [260,] 0 1 0
#> [261,] 0 0 1
#> [262,] 0 0 1
#> [263,] 1 0 0
#> [264,] 0 1 0
#> [265,] 0 1 0
#> [266,] 0 0 1
#> [267,] 0 0 1
#> [268,] 0 0 1
#> [269,] 1 0 0
#> [270,] 1 0 0
#> [271,] 0 1 0
#> [272,] 0 0 1
#> [273,] 0 1 0
#> [274,] 0 1 0
#> [275,] 1 0 0
#> [276,] 0 0 1
#> [277,] 1 0 0
#> [278,] 1 0 0
#> [279,] 1 0 0
#> [280,] 0 0 1
#> [281,] 0 0 1
#> [282,] 0 0 1
#> [283,] 1 0 0
#> [284,] 0 0 1
#> [285,] 0 0 1
#> [286,] 0 1 0
#> [287,] 0 0 1
#> [288,] 1 0 0
#> [289,] 0 0 1
#> [290,] 0 0 1
#> [291,] 1 0 0
#> [292,] 1 0 0
#> [293,] 0 0 1
#> [294,] 0 0 1
#> [295,] 0 0 1
#> [296,] 0 1 0
#> [297,] 0 1 0
#> [298,] 1 0 0
#> [299,] 1 0 0
#> [300,] 0 1 0
#> [301,] 1 0 0
#> [302,] 1 0 0
#> [303,] 0 1 0
#> [304,] 1 0 0
#> [305,] 0 1 0
#> [306,] 0 1 0
#> [307,] 0 1 0
#> [308,] 0 0 1
#> [309,] 0 1 0
#> [310,] 1 0 0
#> [311,] 1 0 0
#> [312,] 0 1 0
#> [313,] 1 0 0
#> [314,] 0 1 0
#> [315,] 1 0 0
#> [316,] 1 0 0
#> [317,] 0 1 0
#> [318,] 0 0 1
#> [319,] 1 0 0
#> [320,] 1 0 0
#> [321,] 1 0 0
#> [322,] 0 1 0
#> [323,] 1 0 0
#> [324,] 0 1 0
#> [325,] 0 1 0
#> [326,] 1 0 0
#> [327,] 0 0 1
#> [328,] 1 0 0
#> [329,] 1 0 0
#> [330,] 0 1 0
#> [331,] 1 0 0
#> [332,] 0 0 1
#> [333,] 0 1 0
#> [334,] 1 0 0
#> [335,] 0 0 1
#> [336,] 0 1 0
#> [337,] 0 0 1
#> [338,] 0 1 0
#> [339,] 1 0 0
#> [340,] 0 0 1
#> [341,] 1 0 0
#> [342,] 1 0 0
#> [343,] 1 0 0
#> [344,] 1 0 0
#> [345,] 0 1 0
#> [346,] 0 1 0
#> [347,] 1 0 0
#> [348,] 1 0 0
#> [349,] 1 0 0
#> [350,] 0 0 1
#> [351,] 0 1 0
#> [352,] 1 0 0
#> [353,] 0 0 1
#> [354,] 0 0 1
#> [355,] 0 1 0
#> [356,] 1 0 0
#> [357,] 0 1 0
#> [358,] 0 0 1
#> [359,] 1 0 0
#> [360,] 0 0 1
#> [361,] 1 0 0
#> [362,] 1 0 0
#> [363,] 0 1 0
#> [364,] 0 0 1
#> [365,] 1 0 0
#> [366,] 1 0 0
#> [367,] 0 1 0
#> [368,] 1 0 0
#> [369,] 1 0 0
#> [370,] 0 0 1
#> [371,] 0 0 1
#> [372,] 0 1 0
#> [373,] 0 0 1
#> [374,] 1 0 0
#> [375,] 1 0 0
#> [376,] 1 0 0
#> [377,] 0 1 0
#> [378,] 1 0 0
#> [379,] 1 0 0
#> [380,] 0 0 1
#> [381,] 1 0 0
#> [382,] 0 1 0
#> [383,] 0 0 1
#> [384,] 0 1 0
#> [385,] 1 0 0
#> [386,] 1 0 0
#> [387,] 0 0 1
#> [388,] 0 0 1
#> [389,] 0 0 1
#> [390,] 0 1 0
#> [391,] 1 0 0
#> [392,] 0 0 1
#> [393,] 0 0 1
#> [394,] 1 0 0
#> [395,] 1 0 0
#> [396,] 1 0 0
#> [397,] 1 0 0
#> [398,] 0 1 0
#> [399,] 0 0 1
#> [400,] 0 0 1
#> [401,] 1 0 0
#> lung_disease=no lung_disease=yes exercise_freq=low
#> [1,] 0 1 0
#> [2,] 1 0 1
#> [3,] 1 0 0
#> [4,] 1 0 0
#> [5,] 1 0 1
#> [6,] 1 0 1
#> [7,] 1 0 0
#> [8,] 1 0 0
#> [9,] 1 0 0
#> [10,] 1 0 0
#> [11,] 1 0 0
#> [12,] 1 0 0
#> [13,] 1 0 1
#> [14,] 0 1 0
#> [15,] 0 1 1
#> [16,] 1 0 1
#> [17,] 1 0 0
#> [18,] 1 0 0
#> [19,] 1 0 1
#> [20,] 1 0 0
#> [21,] 0 1 1
#> [22,] 1 0 0
#> [23,] 1 0 1
#> [24,] 1 0 0
#> [25,] 1 0 1
#> [26,] 0 1 0
#> [27,] 1 0 1
#> [28,] 1 0 0
#> [29,] 1 0 1
#> [30,] 1 0 0
#> [31,] 1 0 0
#> [32,] 0 1 0
#> [33,] 1 0 1
#> [34,] 1 0 1
#> [35,] 1 0 1
#> [36,] 1 0 0
#> [37,] 1 0 1
#> [38,] 1 0 0
#> [39,] 1 0 0
#> [40,] 1 0 0
#> [41,] 1 0 0
#> [42,] 0 1 0
#> [43,] 1 0 0
#> [44,] 1 0 0
#> [45,] 1 0 1
#> [46,] 0 1 0
#> [47,] 1 0 0
#> [48,] 1 0 1
#> [49,] 1 0 1
#> [50,] 1 0 0
#> [51,] 1 0 0
#> [52,] 1 0 0
#> [53,] 1 0 0
#> [54,] 0 1 0
#> [55,] 1 0 0
#> [56,] 1 0 0
#> [57,] 0 1 1
#> [58,] 1 0 0
#> [59,] 1 0 1
#> [60,] 0 1 0
#> [61,] 1 0 0
#> [62,] 1 0 0
#> [63,] 1 0 0
#> [64,] 1 0 1
#> [65,] 1 0 0
#> [66,] 1 0 1
#> [67,] 1 0 1
#> [68,] 1 0 1
#> [69,] 0 1 0
#> [70,] 1 0 1
#> [71,] 1 0 1
#> [72,] 0 1 0
#> [73,] 1 0 0
#> [74,] 1 0 1
#> [75,] 1 0 0
#> [76,] 1 0 0
#> [77,] 0 1 0
#> [78,] 1 0 1
#> [79,] 1 0 0
#> [80,] 0 1 0
#> [81,] 1 0 1
#> [82,] 0 1 1
#> [83,] 1 0 0
#> [84,] 1 0 1
#> [85,] 0 1 0
#> [86,] 1 0 0
#> [87,] 1 0 1
#> [88,] 1 0 0
#> [89,] 1 0 1
#> [90,] 1 0 0
#> [91,] 1 0 0
#> [92,] 1 0 0
#> [93,] 1 0 0
#> [94,] 1 0 0
#> [95,] 1 0 1
#> [96,] 1 0 1
#> [97,] 1 0 1
#> [98,] 1 0 0
#> [99,] 1 0 0
#> [100,] 1 0 0
#> [101,] 1 0 1
#> [102,] 1 0 0
#> [103,] 1 0 0
#> [104,] 1 0 0
#> [105,] 1 0 0
#> [106,] 1 0 0
#> [107,] 0 1 0
#> [108,] 1 0 0
#> [109,] 1 0 0
#> [110,] 0 1 1
#> [111,] 1 0 1
#> [112,] 1 0 0
#> [113,] 1 0 0
#> [114,] 1 0 0
#> [115,] 1 0 1
#> [116,] 1 0 1
#> [117,] 1 0 1
#> [118,] 1 0 0
#> [119,] 1 0 0
#> [120,] 1 0 1
#> [121,] 1 0 0
#> [122,] 1 0 0
#> [123,] 1 0 1
#> [124,] 1 0 0
#> [125,] 1 0 0
#> [126,] 1 0 1
#> [127,] 0 1 0
#> [128,] 1 0 0
#> [129,] 1 0 1
#> [130,] 0 1 0
#> [131,] 1 0 1
#> [132,] 1 0 0
#> [133,] 1 0 0
#> [134,] 1 0 0
#> [135,] 1 0 1
#> [136,] 1 0 1
#> [137,] 1 0 0
#> [138,] 1 0 1
#> [139,] 1 0 0
#> [140,] 1 0 1
#> [141,] 1 0 0
#> [142,] 1 0 0
#> [143,] 1 0 0
#> [144,] 1 0 1
#> [145,] 1 0 0
#> [146,] 1 0 0
#> [147,] 1 0 1
#> [148,] 0 1 1
#> [149,] 1 0 0
#> [150,] 1 0 0
#> [151,] 1 0 1
#> [152,] 1 0 0
#> [153,] 1 0 0
#> [154,] 1 0 0
#> [155,] 1 0 1
#> [156,] 1 0 0
#> [157,] 1 0 0
#> [158,] 1 0 0
#> [159,] 1 0 0
#> [160,] 1 0 0
#> [161,] 1 0 1
#> [162,] 1 0 1
#> [163,] 0 1 1
#> [164,] 1 0 1
#> [165,] 1 0 1
#> [166,] 1 0 0
#> [167,] 1 0 0
#> [168,] 1 0 1
#> [169,] 1 0 0
#> [170,] 1 0 0
#> [171,] 1 0 1
#> [172,] 1 0 1
#> [173,] 0 1 0
#> [174,] 1 0 0
#> [175,] 1 0 0
#> [176,] 1 0 1
#> [177,] 1 0 1
#> [178,] 1 0 0
#> [179,] 1 0 1
#> [180,] 1 0 0
#> [181,] 0 1 0
#> [182,] 1 0 0
#> [183,] 1 0 0
#> [184,] 1 0 0
#> [185,] 0 1 1
#> [186,] 1 0 0
#> [187,] 0 1 0
#> [188,] 1 0 1
#> [189,] 1 0 1
#> [190,] 1 0 1
#> [191,] 1 0 0
#> [192,] 1 0 0
#> [193,] 1 0 0
#> [194,] 1 0 1
#> [195,] 1 0 0
#> [196,] 1 0 0
#> [197,] 1 0 0
#> [198,] 1 0 1
#> [199,] 1 0 1
#> [200,] 1 0 1
#> [201,] 1 0 0
#> [202,] 1 0 1
#> [203,] 1 0 0
#> [204,] 1 0 0
#> [205,] 1 0 0
#> [206,] 1 0 0
#> [207,] 1 0 0
#> [208,] 1 0 1
#> [209,] 0 1 1
#> [210,] 1 0 1
#> [211,] 1 0 1
#> [212,] 1 0 0
#> [213,] 1 0 0
#> [214,] 1 0 0
#> [215,] 1 0 0
#> [216,] 1 0 0
#> [217,] 1 0 0
#> [218,] 1 0 0
#> [219,] 1 0 0
#> [220,] 1 0 0
#> [221,] 0 1 0
#> [222,] 1 0 0
#> [223,] 1 0 0
#> [224,] 1 0 0
#> [225,] 1 0 0
#> [226,] 1 0 0
#> [227,] 1 0 1
#> [228,] 1 0 0
#> [229,] 1 0 0
#> [230,] 1 0 0
#> [231,] 0 1 0
#> [232,] 1 0 1
#> [233,] 1 0 1
#> [234,] 1 0 1
#> [235,] 0 1 0
#> [236,] 1 0 0
#> [237,] 1 0 0
#> [238,] 1 0 0
#> [239,] 1 0 0
#> [240,] 1 0 0
#> [241,] 1 0 1
#> [242,] 1 0 0
#> [243,] 1 0 0
#> [244,] 1 0 1
#> [245,] 1 0 0
#> [246,] 1 0 0
#> [247,] 1 0 0
#> [248,] 1 0 1
#> [249,] 1 0 0
#> [250,] 1 0 0
#> [251,] 1 0 0
#> [252,] 1 0 0
#> [253,] 1 0 0
#> [254,] 1 0 1
#> [255,] 1 0 0
#> [256,] 1 0 0
#> [257,] 1 0 1
#> [258,] 1 0 0
#> [259,] 1 0 0
#> [260,] 1 0 0
#> [261,] 1 0 0
#> [262,] 1 0 0
#> [263,] 1 0 0
#> [264,] 1 0 0
#> [265,] 0 1 0
#> [266,] 0 1 1
#> [267,] 1 0 1
#> [268,] 1 0 1
#> [269,] 1 0 0
#> [270,] 1 0 1
#> [271,] 1 0 0
#> [272,] 1 0 0
#> [273,] 1 0 0
#> [274,] 1 0 0
#> [275,] 1 0 1
#> [276,] 1 0 1
#> [277,] 1 0 1
#> [278,] 1 0 1
#> [279,] 1 0 0
#> [280,] 1 0 0
#> [281,] 1 0 1
#> [282,] 0 1 0
#> [283,] 1 0 0
#> [284,] 0 1 0
#> [285,] 0 1 0
#> [286,] 1 0 0
#> [287,] 1 0 0
#> [288,] 1 0 0
#> [289,] 1 0 1
#> [290,] 0 1 1
#> [291,] 1 0 1
#> [292,] 1 0 0
#> [293,] 1 0 0
#> [294,] 1 0 0
#> [295,] 1 0 0
#> [296,] 0 1 0
#> [297,] 1 0 0
#> [298,] 1 0 0
#> [299,] 1 0 1
#> [300,] 1 0 0
#> [301,] 1 0 1
#> [302,] 1 0 1
#> [303,] 1 0 1
#> [304,] 1 0 1
#> [305,] 1 0 1
#> [306,] 1 0 1
#> [307,] 1 0 1
#> [308,] 0 1 1
#> [309,] 1 0 1
#> [310,] 1 0 1
#> [311,] 1 0 0
#> [312,] 1 0 0
#> [313,] 1 0 1
#> [314,] 0 1 0
#> [315,] 1 0 0
#> [316,] 1 0 0
#> [317,] 1 0 0
#> [318,] 0 1 0
#> [319,] 1 0 0
#> [320,] 0 1 1
#> [321,] 1 0 0
#> [322,] 1 0 0
#> [323,] 1 0 0
#> [324,] 1 0 1
#> [325,] 1 0 1
#> [326,] 1 0 0
#> [327,] 1 0 1
#> [328,] 1 0 0
#> [329,] 0 1 1
#> [330,] 1 0 0
#> [331,] 1 0 1
#> [332,] 1 0 1
#> [333,] 1 0 1
#> [334,] 1 0 0
#> [335,] 1 0 0
#> [336,] 1 0 1
#> [337,] 1 0 1
#> [338,] 1 0 0
#> [339,] 1 0 1
#> [340,] 1 0 0
#> [341,] 1 0 1
#> [342,] 1 0 0
#> [343,] 1 0 1
#> [344,] 1 0 1
#> [345,] 1 0 0
#> [346,] 0 1 0
#> [347,] 1 0 0
#> [348,] 1 0 0
#> [349,] 1 0 1
#> [350,] 0 1 0
#> [351,] 1 0 0
#> [352,] 1 0 1
#> [353,] 1 0 1
#> [354,] 0 1 0
#> [355,] 1 0 0
#> [356,] 1 0 0
#> [357,] 1 0 1
#> [358,] 0 1 0
#> [359,] 1 0 0
#> [360,] 1 0 1
#> [361,] 1 0 0
#> [362,] 1 0 0
#> [363,] 0 1 0
#> [364,] 0 1 0
#> [365,] 1 0 0
#> [366,] 1 0 0
#> [367,] 1 0 0
#> [368,] 1 0 0
#> [369,] 1 0 0
#> [370,] 1 0 0
#> [371,] 0 1 0
#> [372,] 1 0 0
#> [373,] 0 1 0
#> [374,] 1 0 0
#> [375,] 1 0 0
#> [376,] 1 0 1
#> [377,] 1 0 0
#> [378,] 1 0 0
#> [379,] 1 0 0
#> [380,] 0 1 1
#> [381,] 1 0 0
#> [382,] 0 1 1
#> [383,] 1 0 0
#> [384,] 1 0 1
#> [385,] 1 0 0
#> [386,] 1 0 0
#> [387,] 0 1 0
#> [388,] 1 0 1
#> [389,] 0 1 1
#> [390,] 1 0 0
#> [391,] 1 0 0
#> [392,] 1 0 1
#> [393,] 0 1 0
#> [394,] 1 0 0
#> [395,] 1 0 0
#> [396,] 0 1 1
#> [397,] 1 0 0
#> [398,] 1 0 0
#> [399,] 0 1 0
#> [400,] 1 0 0
#> [401,] 1 0 0
#> exercise_freq=moderate exercise_freq=high bmi_category=underweight
#> [1,] 1 0 0
#> [2,] 0 0 0
#> [3,] 1 0 0
#> [4,] 1 0 0
#> [5,] 0 0 0
#> [6,] 0 0 0
#> [7,] 1 0 0
#> [8,] 1 0 0
#> [9,] 0 1 0
#> [10,] 0 1 0
#> [11,] 0 1 0
#> [12,] 1 0 0
#> [13,] 0 0 0
#> [14,] 1 0 0
#> [15,] 0 0 0
#> [16,] 0 0 0
#> [17,] 1 0 0
#> [18,] 1 0 0
#> [19,] 0 0 0
#> [20,] 0 1 0
#> [21,] 0 0 0
#> [22,] 1 0 0
#> [23,] 0 0 0
#> [24,] 0 1 0
#> [25,] 0 0 0
#> [26,] 0 1 0
#> [27,] 0 0 0
#> [28,] 0 1 0
#> [29,] 0 0 0
#> [30,] 1 0 0
#> [31,] 1 0 0
#> [32,] 1 0 0
#> [33,] 0 0 0
#> [34,] 0 0 0
#> [35,] 0 0 0
#> [36,] 1 0 0
#> [37,] 0 0 0
#> [38,] 1 0 0
#> [39,] 1 0 0
#> [40,] 0 1 0
#> [41,] 0 1 0
#> [42,] 0 1 0
#> [43,] 1 0 0
#> [44,] 0 1 0
#> [45,] 0 0 0
#> [46,] 1 0 0
#> [47,] 0 1 0
#> [48,] 0 0 0
#> [49,] 0 0 0
#> [50,] 1 0 0
#> [51,] 1 0 0
#> [52,] 1 0 0
#> [53,] 1 0 1
#> [54,] 0 1 0
#> [55,] 1 0 0
#> [56,] 1 0 0
#> [57,] 0 0 0
#> [58,] 0 1 0
#> [59,] 0 0 0
#> [60,] 0 1 0
#> [61,] 0 1 0
#> [62,] 1 0 0
#> [63,] 0 1 0
#> [64,] 0 0 0
#> [65,] 1 0 0
#> [66,] 0 0 0
#> [67,] 0 0 0
#> [68,] 0 0 0
#> [69,] 1 0 0
#> [70,] 0 0 0
#> [71,] 0 0 0
#> [72,] 1 0 0
#> [73,] 1 0 0
#> [74,] 0 0 0
#> [75,] 1 0 0
#> [76,] 0 1 0
#> [77,] 0 1 0
#> [78,] 0 0 0
#> [79,] 1 0 0
#> [80,] 0 1 0
#> [81,] 0 0 0
#> [82,] 0 0 0
#> [83,] 0 1 0
#> [84,] 0 0 0
#> [85,] 0 1 0
#> [86,] 1 0 0
#> [87,] 0 0 0
#> [88,] 0 1 0
#> [89,] 0 0 0
#> [90,] 1 0 0
#> [91,] 0 1 0
#> [92,] 1 0 0
#> [93,] 0 1 0
#> [94,] 0 1 0
#> [95,] 0 0 0
#> [96,] 0 0 0
#> [97,] 0 0 0
#> [98,] 1 0 0
#> [99,] 1 0 0
#> [100,] 1 0 0
#> [101,] 0 0 0
#> [102,] 0 1 0
#> [103,] 1 0 0
#> [104,] 0 1 1
#> [105,] 1 0 0
#> [106,] 0 1 0
#> [107,] 0 1 0
#> [108,] 1 0 0
#> [109,] 0 1 0
#> [110,] 0 0 0
#> [111,] 0 0 0
#> [112,] 0 1 0
#> [113,] 0 1 0
#> [114,] 1 0 0
#> [115,] 0 0 1
#> [116,] 0 0 0
#> [117,] 0 0 0
#> [118,] 0 1 0
#> [119,] 0 1 0
#> [120,] 0 0 0
#> [121,] 0 1 0
#> [122,] 1 0 0
#> [123,] 0 0 0
#> [124,] 0 1 0
#> [125,] 1 0 0
#> [126,] 0 0 0
#> [127,] 1 0 0
#> [128,] 1 0 0
#> [129,] 0 0 0
#> [130,] 1 0 0
#> [131,] 0 0 0
#> [132,] 1 0 0
#> [133,] 1 0 0
#> [134,] 1 0 0
#> [135,] 0 0 0
#> [136,] 0 0 0
#> [137,] 0 1 0
#> [138,] 0 0 0
#> [139,] 0 1 0
#> [140,] 0 0 0
#> [141,] 0 1 0
#> [142,] 0 1 0
#> [143,] 1 0 0
#> [144,] 0 0 0
#> [145,] 1 0 0
#> [146,] 0 1 0
#> [147,] 0 0 0
#> [148,] 0 0 0
#> [149,] 1 0 0
#> [150,] 1 0 0
#> [151,] 0 0 1
#> [152,] 1 0 0
#> [153,] 0 1 0
#> [154,] 1 0 0
#> [155,] 0 0 0
#> [156,] 1 0 0
#> [157,] 0 1 0
#> [158,] 1 0 0
#> [159,] 1 0 0
#> [160,] 1 0 0
#> [161,] 0 0 0
#> [162,] 0 0 0
#> [163,] 0 0 0
#> [164,] 0 0 0
#> [165,] 0 0 0
#> [166,] 1 0 0
#> [167,] 0 1 0
#> [168,] 0 0 0
#> [169,] 1 0 0
#> [170,] 1 0 0
#> [171,] 0 0 0
#> [172,] 0 0 0
#> [173,] 0 1 0
#> [174,] 0 1 0
#> [175,] 1 0 0
#> [176,] 0 0 0
#> [177,] 0 0 0
#> [178,] 1 0 0
#> [179,] 0 0 0
#> [180,] 1 0 0
#> [181,] 0 1 0
#> [182,] 1 0 0
#> [183,] 1 0 0
#> [184,] 0 1 0
#> [185,] 0 0 0
#> [186,] 0 1 0
#> [187,] 1 0 0
#> [188,] 0 0 0
#> [189,] 0 0 0
#> [190,] 0 0 0
#> [191,] 1 0 0
#> [192,] 0 1 0
#> [193,] 1 0 0
#> [194,] 0 0 0
#> [195,] 1 0 0
#> [196,] 1 0 0
#> [197,] 0 1 0
#> [198,] 0 0 0
#> [199,] 0 0 0
#> [200,] 0 0 0
#> [201,] 1 0 0
#> [202,] 0 0 0
#> [203,] 1 0 0
#> [204,] 0 1 0
#> [205,] 1 0 0
#> [206,] 1 0 0
#> [207,] 1 0 0
#> [208,] 0 0 0
#> [209,] 0 0 0
#> [210,] 0 0 0
#> [211,] 0 0 0
#> [212,] 1 0 0
#> [213,] 0 1 0
#> [214,] 1 0 0
#> [215,] 0 1 0
#> [216,] 0 1 0
#> [217,] 1 0 0
#> [218,] 1 0 0
#> [219,] 0 1 0
#> [220,] 0 1 0
#> [221,] 0 1 0
#> [222,] 0 1 0
#> [223,] 1 0 0
#> [224,] 0 1 0
#> [225,] 0 1 0
#> [226,] 1 0 0
#> [227,] 0 0 0
#> [228,] 1 0 0
#> [229,] 0 1 0
#> [230,] 1 0 0
#> [231,] 1 0 0
#> [232,] 0 0 0
#> [233,] 0 0 0
#> [234,] 0 0 0
#> [235,] 0 1 0
#> [236,] 0 1 0
#> [237,] 0 1 0
#> [238,] 1 0 0
#> [239,] 1 0 0
#> [240,] 0 1 0
#> [241,] 0 0 0
#> [242,] 1 0 0
#> [243,] 1 0 0
#> [244,] 0 0 0
#> [245,] 1 0 0
#> [246,] 0 1 0
#> [247,] 0 1 0
#> [248,] 0 0 0
#> [249,] 0 1 0
#> [250,] 0 1 0
#> [251,] 1 0 0
#> [252,] 1 0 0
#> [253,] 1 0 0
#> [254,] 0 0 0
#> [255,] 1 0 0
#> [256,] 0 1 0
#> [257,] 0 0 0
#> [258,] 0 1 0
#> [259,] 0 1 0
#> [260,] 0 1 0
#> [261,] 1 0 0
#> [262,] 1 0 0
#> [263,] 0 1 0
#> [264,] 1 0 0
#> [265,] 0 1 0
#> [266,] 0 0 0
#> [267,] 0 0 0
#> [268,] 0 0 0
#> [269,] 1 0 0
#> [270,] 0 0 0
#> [271,] 1 0 0
#> [272,] 1 0 0
#> [273,] 1 0 0
#> [274,] 1 0 0
#> [275,] 0 0 0
#> [276,] 0 0 0
#> [277,] 0 0 0
#> [278,] 0 0 0
#> [279,] 1 0 0
#> [280,] 0 1 0
#> [281,] 0 0 0
#> [282,] 1 0 0
#> [283,] 1 0 0
#> [284,] 1 0 0
#> [285,] 0 1 0
#> [286,] 0 1 0
#> [287,] 0 1 0
#> [288,] 0 1 0
#> [289,] 0 0 0
#> [290,] 0 0 0
#> [291,] 0 0 0
#> [292,] 1 0 0
#> [293,] 1 0 0
#> [294,] 1 0 0
#> [295,] 1 0 0
#> [296,] 1 0 0
#> [297,] 1 0 0
#> [298,] 1 0 0
#> [299,] 0 0 0
#> [300,] 0 1 1
#> [301,] 0 0 0
#> [302,] 0 0 0
#> [303,] 0 0 0
#> [304,] 0 0 0
#> [305,] 0 0 0
#> [306,] 0 0 0
#> [307,] 0 0 0
#> [308,] 0 0 0
#> [309,] 0 0 0
#> [310,] 0 0 0
#> [311,] 1 0 0
#> [312,] 1 0 0
#> [313,] 0 0 0
#> [314,] 1 0 0
#> [315,] 1 0 0
#> [316,] 1 0 0
#> [317,] 1 0 0
#> [318,] 0 1 0
#> [319,] 1 0 0
#> [320,] 0 0 0
#> [321,] 1 0 0
#> [322,] 0 1 0
#> [323,] 0 1 0
#> [324,] 0 0 1
#> [325,] 0 0 0
#> [326,] 0 1 0
#> [327,] 0 0 0
#> [328,] 1 0 1
#> [329,] 0 0 0
#> [330,] 0 1 0
#> [331,] 0 0 0
#> [332,] 0 0 0
#> [333,] 0 0 0
#> [334,] 0 1 0
#> [335,] 1 0 0
#> [336,] 0 0 0
#> [337,] 0 0 0
#> [338,] 0 1 0
#> [339,] 0 0 0
#> [340,] 1 0 0
#> [341,] 0 0 0
#> [342,] 0 1 0
#> [343,] 0 0 0
#> [344,] 0 0 0
#> [345,] 1 0 0
#> [346,] 1 0 0
#> [347,] 1 0 0
#> [348,] 1 0 0
#> [349,] 0 0 0
#> [350,] 0 1 0
#> [351,] 1 0 0
#> [352,] 0 0 0
#> [353,] 0 0 0
#> [354,] 0 1 0
#> [355,] 0 1 0
#> [356,] 0 1 0
#> [357,] 0 0 0
#> [358,] 0 1 0
#> [359,] 0 1 0
#> [360,] 0 0 0
#> [361,] 0 1 0
#> [362,] 1 0 0
#> [363,] 1 0 0
#> [364,] 1 0 0
#> [365,] 0 1 1
#> [366,] 1 0 0
#> [367,] 1 0 0
#> [368,] 0 1 0
#> [369,] 1 0 0
#> [370,] 0 1 0
#> [371,] 1 0 0
#> [372,] 0 1 0
#> [373,] 1 0 0
#> [374,] 1 0 0
#> [375,] 0 1 1
#> [376,] 0 0 0
#> [377,] 1 0 0
#> [378,] 1 0 0
#> [379,] 0 1 0
#> [380,] 0 0 0
#> [381,] 0 1 0
#> [382,] 0 0 0
#> [383,] 1 0 0
#> [384,] 0 0 0
#> [385,] 0 1 0
#> [386,] 0 1 0
#> [387,] 0 1 0
#> [388,] 0 0 0
#> [389,] 0 0 0
#> [390,] 0 1 0
#> [391,] 0 1 0
#> [392,] 0 0 0
#> [393,] 1 0 0
#> [394,] 0 1 0
#> [395,] 0 1 0
#> [396,] 0 0 0
#> [397,] 0 1 0
#> [398,] 1 0 0
#> [399,] 1 0 0
#> [400,] 0 1 0
#> [401,] 1 0 0
#> bmi_category=normal bmi_category=overweight bmi_category=obese
#> [1,] 1 0 0
#> [2,] 0 1 0
#> [3,] 1 0 0
#> [4,] 0 1 0
#> [5,] 0 0 1
#> [6,] 0 0 1
#> [7,] 0 1 0
#> [8,] 1 0 0
#> [9,] 0 1 0
#> [10,] 0 1 0
#> [11,] 0 1 0
#> [12,] 0 1 0
#> [13,] 1 0 0
#> [14,] 1 0 0
#> [15,] 0 0 1
#> [16,] 0 0 1
#> [17,] 0 1 0
#> [18,] 0 1 0
#> [19,] 0 1 0
#> [20,] 1 0 0
#> [21,] 1 0 0
#> [22,] 1 0 0
#> [23,] 0 0 1
#> [24,] 1 0 0
#> [25,] 0 1 0
#> [26,] 1 0 0
#> [27,] 0 0 1
#> [28,] 1 0 0
#> [29,] 1 0 0
#> [30,] 1 0 0
#> [31,] 0 1 0
#> [32,] 0 1 0
#> [33,] 1 0 0
#> [34,] 0 0 1
#> [35,] 0 0 1
#> [36,] 1 0 0
#> [37,] 1 0 0
#> [38,] 1 0 0
#> [39,] 0 1 0
#> [40,] 1 0 0
#> [41,] 1 0 0
#> [42,] 1 0 0
#> [43,] 0 0 1
#> [44,] 0 0 1
#> [45,] 0 0 1
#> [46,] 1 0 0
#> [47,] 1 0 0
#> [48,] 0 1 0
#> [49,] 1 0 0
#> [50,] 0 1 0
#> [51,] 1 0 0
#> [52,] 0 0 1
#> [53,] 0 0 0
#> [54,] 1 0 0
#> [55,] 0 0 1
#> [56,] 1 0 0
#> [57,] 0 1 0
#> [58,] 1 0 0
#> [59,] 0 0 1
#> [60,] 1 0 0
#> [61,] 0 1 0
#> [62,] 1 0 0
#> [63,] 0 1 0
#> [64,] 0 1 0
#> [65,] 1 0 0
#> [66,] 1 0 0
#> [67,] 1 0 0
#> [68,] 1 0 0
#> [69,] 1 0 0
#> [70,] 0 0 1
#> [71,] 0 1 0
#> [72,] 1 0 0
#> [73,] 1 0 0
#> [74,] 0 0 1
#> [75,] 0 1 0
#> [76,] 0 1 0
#> [77,] 1 0 0
#> [78,] 0 0 1
#> [79,] 1 0 0
#> [80,] 1 0 0
#> [81,] 0 0 1
#> [82,] 0 1 0
#> [83,] 0 1 0
#> [84,] 0 0 1
#> [85,] 0 1 0
#> [86,] 1 0 0
#> [87,] 0 1 0
#> [88,] 1 0 0
#> [89,] 0 1 0
#> [90,] 0 1 0
#> [91,] 1 0 0
#> [92,] 1 0 0
#> [93,] 1 0 0
#> [94,] 1 0 0
#> [95,] 0 0 1
#> [96,] 1 0 0
#> [97,] 0 0 1
#> [98,] 0 1 0
#> [99,] 0 1 0
#> [100,] 0 1 0
#> [101,] 0 1 0
#> [102,] 0 1 0
#> [103,] 1 0 0
#> [104,] 0 0 0
#> [105,] 1 0 0
#> [106,] 0 1 0
#> [107,] 1 0 0
#> [108,] 1 0 0
#> [109,] 0 1 0
#> [110,] 0 0 1
#> [111,] 0 0 1
#> [112,] 0 0 1
#> [113,] 0 0 1
#> [114,] 0 1 0
#> [115,] 0 0 0
#> [116,] 0 1 0
#> [117,] 1 0 0
#> [118,] 0 0 1
#> [119,] 1 0 0
#> [120,] 0 1 0
#> [121,] 0 1 0
#> [122,] 0 1 0
#> [123,] 0 0 1
#> [124,] 1 0 0
#> [125,] 1 0 0
#> [126,] 0 0 1
#> [127,] 0 0 1
#> [128,] 1 0 0
#> [129,] 0 0 1
#> [130,] 1 0 0
#> [131,] 0 1 0
#> [132,] 0 1 0
#> [133,] 0 0 1
#> [134,] 0 0 1
#> [135,] 0 0 1
#> [136,] 1 0 0
#> [137,] 1 0 0
#> [138,] 0 0 1
#> [139,] 1 0 0
#> [140,] 0 0 1
#> [141,] 0 1 0
#> [142,] 1 0 0
#> [143,] 0 1 0
#> [144,] 0 1 0
#> [145,] 0 0 1
#> [146,] 1 0 0
#> [147,] 0 1 0
#> [148,] 1 0 0
#> [149,] 0 1 0
#> [150,] 1 0 0
#> [151,] 0 0 0
#> [152,] 0 1 0
#> [153,] 1 0 0
#> [154,] 0 0 1
#> [155,] 1 0 0
#> [156,] 1 0 0
#> [157,] 1 0 0
#> [158,] 1 0 0
#> [159,] 1 0 0
#> [160,] 0 1 0
#> [161,] 1 0 0
#> [162,] 1 0 0
#> [163,] 1 0 0
#> [164,] 1 0 0
#> [165,] 1 0 0
#> [166,] 0 0 1
#> [167,] 0 1 0
#> [168,] 1 0 0
#> [169,] 0 1 0
#> [170,] 0 1 0
#> [171,] 0 1 0
#> [172,] 1 0 0
#> [173,] 0 1 0
#> [174,] 0 0 1
#> [175,] 0 0 1
#> [176,] 1 0 0
#> [177,] 1 0 0
#> [178,] 0 1 0
#> [179,] 0 0 1
#> [180,] 0 1 0
#> [181,] 1 0 0
#> [182,] 0 1 0
#> [183,] 1 0 0
#> [184,] 1 0 0
#> [185,] 1 0 0
#> [186,] 1 0 0
#> [187,] 0 1 0
#> [188,] 0 0 1
#> [189,] 1 0 0
#> [190,] 1 0 0
#> [191,] 1 0 0
#> [192,] 0 0 1
#> [193,] 1 0 0
#> [194,] 0 1 0
#> [195,] 0 1 0
#> [196,] 1 0 0
#> [197,] 0 1 0
#> [198,] 0 1 0
#> [199,] 1 0 0
#> [200,] 0 0 1
#> [201,] 0 1 0
#> [202,] 0 0 1
#> [203,] 0 1 0
#> [204,] 1 0 0
#> [205,] 0 0 1
#> [206,] 1 0 0
#> [207,] 1 0 0
#> [208,] 0 1 0
#> [209,] 0 0 1
#> [210,] 0 1 0
#> [211,] 0 1 0
#> [212,] 1 0 0
#> [213,] 1 0 0
#> [214,] 0 1 0
#> [215,] 0 0 1
#> [216,] 0 1 0
#> [217,] 0 1 0
#> [218,] 1 0 0
#> [219,] 1 0 0
#> [220,] 1 0 0
#> [221,] 0 1 0
#> [222,] 1 0 0
#> [223,] 0 1 0
#> [224,] 1 0 0
#> [225,] 1 0 0
#> [226,] 1 0 0
#> [227,] 0 1 0
#> [228,] 0 0 1
#> [229,] 0 1 0
#> [230,] 0 0 1
#> [231,] 0 1 0
#> [232,] 0 1 0
#> [233,] 0 0 1
#> [234,] 0 1 0
#> [235,] 1 0 0
#> [236,] 0 1 0
#> [237,] 1 0 0
#> [238,] 1 0 0
#> [239,] 0 1 0
#> [240,] 0 0 1
#> [241,] 0 0 1
#> [242,] 1 0 0
#> [243,] 1 0 0
#> [244,] 0 0 1
#> [245,] 0 0 1
#> [246,] 1 0 0
#> [247,] 0 0 1
#> [248,] 1 0 0
#> [249,] 0 0 1
#> [250,] 1 0 0
#> [251,] 0 1 0
#> [252,] 0 0 1
#> [253,] 0 0 1
#> [254,] 0 1 0
#> [255,] 0 1 0
#> [256,] 1 0 0
#> [257,] 1 0 0
#> [258,] 0 1 0
#> [259,] 0 0 1
#> [260,] 0 1 0
#> [261,] 1 0 0
#> [262,] 1 0 0
#> [263,] 1 0 0
#> [264,] 1 0 0
#> [265,] 1 0 0
#> [266,] 0 0 1
#> [267,] 0 0 1
#> [268,] 0 1 0
#> [269,] 0 1 0
#> [270,] 1 0 0
#> [271,] 1 0 0
#> [272,] 0 0 1
#> [273,] 1 0 0
#> [274,] 0 0 1
#> [275,] 1 0 0
#> [276,] 1 0 0
#> [277,] 1 0 0
#> [278,] 1 0 0
#> [279,] 0 1 0
#> [280,] 0 1 0
#> [281,] 1 0 0
#> [282,] 1 0 0
#> [283,] 1 0 0
#> [284,] 0 1 0
#> [285,] 0 1 0
#> [286,] 0 0 1
#> [287,] 1 0 0
#> [288,] 0 1 0
#> [289,] 0 1 0
#> [290,] 0 0 1
#> [291,] 0 0 1
#> [292,] 0 1 0
#> [293,] 0 1 0
#> [294,] 1 0 0
#> [295,] 1 0 0
#> [296,] 1 0 0
#> [297,] 0 1 0
#> [298,] 0 1 0
#> [299,] 0 1 0
#> [300,] 0 0 0
#> [301,] 0 0 1
#> [302,] 0 1 0
#> [303,] 1 0 0
#> [304,] 0 0 1
#> [305,] 1 0 0
#> [306,] 0 0 1
#> [307,] 0 1 0
#> [308,] 0 1 0
#> [309,] 0 1 0
#> [310,] 1 0 0
#> [311,] 0 0 1
#> [312,] 1 0 0
#> [313,] 0 1 0
#> [314,] 1 0 0
#> [315,] 1 0 0
#> [316,] 0 1 0
#> [317,] 1 0 0
#> [318,] 1 0 0
#> [319,] 0 1 0
#> [320,] 0 1 0
#> [321,] 0 1 0
#> [322,] 1 0 0
#> [323,] 0 1 0
#> [324,] 0 0 0
#> [325,] 0 1 0
#> [326,] 0 0 1
#> [327,] 1 0 0
#> [328,] 0 0 0
#> [329,] 0 0 1
#> [330,] 0 1 0
#> [331,] 1 0 0
#> [332,] 0 0 1
#> [333,] 0 1 0
#> [334,] 0 0 1
#> [335,] 0 0 1
#> [336,] 1 0 0
#> [337,] 0 0 1
#> [338,] 0 1 0
#> [339,] 0 1 0
#> [340,] 0 0 1
#> [341,] 0 1 0
#> [342,] 1 0 0
#> [343,] 0 0 1
#> [344,] 0 1 0
#> [345,] 0 1 0
#> [346,] 1 0 0
#> [347,] 0 1 0
#> [348,] 1 0 0
#> [349,] 1 0 0
#> [350,] 1 0 0
#> [351,] 1 0 0
#> [352,] 0 1 0
#> [353,] 1 0 0
#> [354,] 1 0 0
#> [355,] 1 0 0
#> [356,] 1 0 0
#> [357,] 0 0 1
#> [358,] 1 0 0
#> [359,] 0 1 0
#> [360,] 0 0 1
#> [361,] 1 0 0
#> [362,] 0 0 1
#> [363,] 1 0 0
#> [364,] 0 1 0
#> [365,] 0 0 0
#> [366,] 0 1 0
#> [367,] 1 0 0
#> [368,] 0 1 0
#> [369,] 1 0 0
#> [370,] 1 0 0
#> [371,] 0 1 0
#> [372,] 1 0 0
#> [373,] 1 0 0
#> [374,] 1 0 0
#> [375,] 0 0 0
#> [376,] 0 0 1
#> [377,] 1 0 0
#> [378,] 0 1 0
#> [379,] 0 0 1
#> [380,] 0 0 1
#> [381,] 1 0 0
#> [382,] 0 0 1
#> [383,] 1 0 0
#> [384,] 0 0 1
#> [385,] 1 0 0
#> [386,] 1 0 0
#> [387,] 0 1 0
#> [388,] 0 1 0
#> [389,] 0 1 0
#> [390,] 1 0 0
#> [391,] 0 0 1
#> [392,] 1 0 0
#> [393,] 0 1 0
#> [394,] 1 0 0
#> [395,] 1 0 0
#> [396,] 0 0 1
#> [397,] 1 0 0
#> [398,] 0 0 1
#> [399,] 1 0 0
#> [400,] 1 0 0
#> [401,] 1 0 0
#> diet_quality=poor diet_quality=fair diet_quality=good
#> [1,] 0 1 0
#> [2,] 1 0 0
#> [3,] 0 0 1
#> [4,] 0 0 1
#> [5,] 0 0 1
#> [6,] 0 0 1
#> [7,] 1 0 0
#> [8,] 1 0 0
#> [9,] 0 1 0
#> [10,] 0 0 1
#> [11,] 0 1 0
#> [12,] 1 0 0
#> [13,] 0 0 1
#> [14,] 0 1 0
#> [15,] 0 1 0
#> [16,] 0 0 1
#> [17,] 0 1 0
#> [18,] 0 0 1
#> [19,] 0 1 0
#> [20,] 0 0 1
#> [21,] 0 0 1
#> [22,] 0 1 0
#> [23,] 0 1 0
#> [24,] 0 0 1
#> [25,] 0 0 1
#> [26,] 1 0 0
#> [27,] 0 0 1
#> [28,] 0 1 0
#> [29,] 0 0 1
#> [30,] 0 1 0
#> [31,] 1 0 0
#> [32,] 1 0 0
#> [33,] 0 0 1
#> [34,] 0 1 0
#> [35,] 1 0 0
#> [36,] 1 0 0
#> [37,] 1 0 0
#> [38,] 1 0 0
#> [39,] 1 0 0
#> [40,] 0 1 0
#> [41,] 1 0 0
#> [42,] 0 0 1
#> [43,] 0 0 1
#> [44,] 0 1 0
#> [45,] 0 1 0
#> [46,] 1 0 0
#> [47,] 0 1 0
#> [48,] 0 0 1
#> [49,] 0 0 1
#> [50,] 1 0 0
#> [51,] 0 1 0
#> [52,] 1 0 0
#> [53,] 0 1 0
#> [54,] 0 1 0
#> [55,] 1 0 0
#> [56,] 1 0 0
#> [57,] 0 1 0
#> [58,] 0 1 0
#> [59,] 0 0 1
#> [60,] 0 0 1
#> [61,] 0 0 1
#> [62,] 0 1 0
#> [63,] 1 0 0
#> [64,] 1 0 0
#> [65,] 0 0 1
#> [66,] 1 0 0
#> [67,] 1 0 0
#> [68,] 1 0 0
#> [69,] 0 0 1
#> [70,] 0 0 1
#> [71,] 0 1 0
#> [72,] 1 0 0
#> [73,] 0 1 0
#> [74,] 0 1 0
#> [75,] 0 1 0
#> [76,] 1 0 0
#> [77,] 0 0 1
#> [78,] 0 1 0
#> [79,] 1 0 0
#> [80,] 1 0 0
#> [81,] 1 0 0
#> [82,] 0 0 1
#> [83,] 0 0 1
#> [84,] 1 0 0
#> [85,] 0 1 0
#> [86,] 1 0 0
#> [87,] 0 0 1
#> [88,] 0 0 1
#> [89,] 0 0 1
#> [90,] 1 0 0
#> [91,] 0 0 1
#> [92,] 0 1 0
#> [93,] 0 1 0
#> [94,] 0 0 1
#> [95,] 0 0 1
#> [96,] 0 1 0
#> [97,] 1 0 0
#> [98,] 0 1 0
#> [99,] 0 1 0
#> [100,] 0 1 0
#> [101,] 1 0 0
#> [102,] 0 0 1
#> [103,] 0 1 0
#> [104,] 0 0 1
#> [105,] 1 0 0
#> [106,] 1 0 0
#> [107,] 0 0 1
#> [108,] 0 1 0
#> [109,] 0 0 1
#> [110,] 0 1 0
#> [111,] 0 1 0
#> [112,] 0 1 0
#> [113,] 1 0 0
#> [114,] 0 0 1
#> [115,] 1 0 0
#> [116,] 1 0 0
#> [117,] 0 0 1
#> [118,] 1 0 0
#> [119,] 1 0 0
#> [120,] 1 0 0
#> [121,] 0 0 1
#> [122,] 1 0 0
#> [123,] 0 1 0
#> [124,] 0 0 1
#> [125,] 0 1 0
#> [126,] 1 0 0
#> [127,] 1 0 0
#> [128,] 0 0 1
#> [129,] 0 1 0
#> [130,] 0 1 0
#> [131,] 1 0 0
#> [132,] 0 1 0
#> [133,] 0 1 0
#> [134,] 0 1 0
#> [135,] 1 0 0
#> [136,] 1 0 0
#> [137,] 0 1 0
#> [138,] 0 1 0
#> [139,] 0 0 1
#> [140,] 1 0 0
#> [141,] 0 1 0
#> [142,] 1 0 0
#> [143,] 0 0 1
#> [144,] 1 0 0
#> [145,] 0 1 0
#> [146,] 0 0 1
#> [147,] 1 0 0
#> [148,] 0 1 0
#> [149,] 0 0 1
#> [150,] 0 0 1
#> [151,] 0 0 1
#> [152,] 1 0 0
#> [153,] 0 0 1
#> [154,] 1 0 0
#> [155,] 0 0 1
#> [156,] 0 1 0
#> [157,] 1 0 0
#> [158,] 0 0 1
#> [159,] 0 0 1
#> [160,] 1 0 0
#> [161,] 0 0 1
#> [162,] 1 0 0
#> [163,] 0 1 0
#> [164,] 0 0 1
#> [165,] 0 0 1
#> [166,] 0 1 0
#> [167,] 1 0 0
#> [168,] 0 0 1
#> [169,] 0 0 1
#> [170,] 0 1 0
#> [171,] 1 0 0
#> [172,] 0 1 0
#> [173,] 0 1 0
#> [174,] 0 1 0
#> [175,] 1 0 0
#> [176,] 0 0 1
#> [177,] 0 1 0
#> [178,] 1 0 0
#> [179,] 1 0 0
#> [180,] 0 1 0
#> [181,] 0 0 1
#> [182,] 0 0 1
#> [183,] 0 1 0
#> [184,] 1 0 0
#> [185,] 0 0 1
#> [186,] 0 0 1
#> [187,] 0 0 1
#> [188,] 1 0 0
#> [189,] 1 0 0
#> [190,] 0 1 0
#> [191,] 0 1 0
#> [192,] 1 0 0
#> [193,] 0 1 0
#> [194,] 1 0 0
#> [195,] 0 1 0
#> [196,] 0 0 1
#> [197,] 0 1 0
#> [198,] 1 0 0
#> [199,] 1 0 0
#> [200,] 0 1 0
#> [201,] 1 0 0
#> [202,] 0 0 1
#> [203,] 1 0 0
#> [204,] 1 0 0
#> [205,] 1 0 0
#> [206,] 0 0 1
#> [207,] 0 1 0
#> [208,] 0 0 1
#> [209,] 0 0 1
#> [210,] 1 0 0
#> [211,] 1 0 0
#> [212,] 1 0 0
#> [213,] 0 0 1
#> [214,] 1 0 0
#> [215,] 0 0 1
#> [216,] 1 0 0
#> [217,] 0 0 1
#> [218,] 0 1 0
#> [219,] 0 0 1
#> [220,] 0 0 1
#> [221,] 1 0 0
#> [222,] 0 0 1
#> [223,] 0 1 0
#> [224,] 0 1 0
#> [225,] 0 0 1
#> [226,] 1 0 0
#> [227,] 0 1 0
#> [228,] 1 0 0
#> [229,] 0 0 1
#> [230,] 0 1 0
#> [231,] 0 1 0
#> [232,] 0 0 1
#> [233,] 0 0 1
#> [234,] 1 0 0
#> [235,] 0 0 1
#> [236,] 0 1 0
#> [237,] 0 0 1
#> [238,] 0 1 0
#> [239,] 0 0 1
#> [240,] 0 1 0
#> [241,] 0 1 0
#> [242,] 0 1 0
#> [243,] 0 1 0
#> [244,] 0 1 0
#> [245,] 0 0 1
#> [246,] 0 0 1
#> [247,] 1 0 0
#> [248,] 0 1 0
#> [249,] 0 0 1
#> [250,] 0 1 0
#> [251,] 0 1 0
#> [252,] 0 0 1
#> [253,] 0 0 1
#> [254,] 0 1 0
#> [255,] 0 0 1
#> [256,] 0 1 0
#> [257,] 0 0 1
#> [258,] 0 0 1
#> [259,] 1 0 0
#> [260,] 1 0 0
#> [261,] 0 0 1
#> [262,] 0 0 1
#> [263,] 1 0 0
#> [264,] 0 0 1
#> [265,] 0 0 1
#> [266,] 0 1 0
#> [267,] 1 0 0
#> [268,] 0 0 1
#> [269,] 0 1 0
#> [270,] 1 0 0
#> [271,] 0 1 0
#> [272,] 0 1 0
#> [273,] 1 0 0
#> [274,] 1 0 0
#> [275,] 0 0 1
#> [276,] 1 0 0
#> [277,] 1 0 0
#> [278,] 0 1 0
#> [279,] 0 1 0
#> [280,] 0 1 0
#> [281,] 0 0 1
#> [282,] 0 0 1
#> [283,] 1 0 0
#> [284,] 0 1 0
#> [285,] 0 0 1
#> [286,] 0 1 0
#> [287,] 0 0 1
#> [288,] 0 1 0
#> [289,] 0 1 0
#> [290,] 1 0 0
#> [291,] 1 0 0
#> [292,] 0 0 1
#> [293,] 0 1 0
#> [294,] 0 1 0
#> [295,] 0 1 0
#> [296,] 0 0 1
#> [297,] 0 1 0
#> [298,] 0 0 1
#> [299,] 1 0 0
#> [300,] 0 1 0
#> [301,] 0 1 0
#> [302,] 0 1 0
#> [303,] 0 0 1
#> [304,] 0 1 0
#> [305,] 0 0 1
#> [306,] 0 1 0
#> [307,] 0 1 0
#> [308,] 0 1 0
#> [309,] 0 1 0
#> [310,] 0 0 1
#> [311,] 0 1 0
#> [312,] 1 0 0
#> [313,] 0 0 1
#> [314,] 0 1 0
#> [315,] 0 0 1
#> [316,] 0 1 0
#> [317,] 0 1 0
#> [318,] 1 0 0
#> [319,] 0 1 0
#> [320,] 0 0 1
#> [321,] 0 0 1
#> [322,] 0 1 0
#> [323,] 0 0 1
#> [324,] 0 1 0
#> [325,] 0 0 1
#> [326,] 0 0 1
#> [327,] 1 0 0
#> [328,] 0 0 1
#> [329,] 1 0 0
#> [330,] 1 0 0
#> [331,] 0 1 0
#> [332,] 1 0 0
#> [333,] 1 0 0
#> [334,] 1 0 0
#> [335,] 1 0 0
#> [336,] 0 1 0
#> [337,] 1 0 0
#> [338,] 0 1 0
#> [339,] 1 0 0
#> [340,] 0 1 0
#> [341,] 0 0 1
#> [342,] 0 0 1
#> [343,] 1 0 0
#> [344,] 0 1 0
#> [345,] 1 0 0
#> [346,] 0 0 1
#> [347,] 1 0 0
#> [348,] 0 1 0
#> [349,] 1 0 0
#> [350,] 0 1 0
#> [351,] 0 1 0
#> [352,] 1 0 0
#> [353,] 1 0 0
#> [354,] 0 0 1
#> [355,] 0 0 1
#> [356,] 0 1 0
#> [357,] 1 0 0
#> [358,] 0 0 1
#> [359,] 0 1 0
#> [360,] 0 0 1
#> [361,] 0 0 1
#> [362,] 0 1 0
#> [363,] 0 0 1
#> [364,] 0 1 0
#> [365,] 0 0 1
#> [366,] 0 1 0
#> [367,] 0 0 1
#> [368,] 0 1 0
#> [369,] 1 0 0
#> [370,] 1 0 0
#> [371,] 0 0 1
#> [372,] 0 1 0
#> [373,] 0 1 0
#> [374,] 0 0 1
#> [375,] 0 1 0
#> [376,] 0 1 0
#> [377,] 0 1 0
#> [378,] 0 1 0
#> [379,] 0 1 0
#> [380,] 1 0 0
#> [381,] 0 0 1
#> [382,] 1 0 0
#> [383,] 0 0 1
#> [384,] 0 0 1
#> [385,] 0 0 1
#> [386,] 1 0 0
#> [387,] 0 0 1
#> [388,] 0 1 0
#> [389,] 1 0 0
#> [390,] 0 1 0
#> [391,] 1 0 0
#> [392,] 0 0 1
#> [393,] 0 0 1
#> [394,] 0 0 1
#> [395,] 1 0 0
#> [396,] 1 0 0
#> [397,] 0 1 0
#> [398,] 1 0 0
#> [399,] 0 1 0
#> [400,] 1 0 0
#> [401,] 1 0 0
#> health_insurance=no health_insurance=yes
#> [1,] 1 0
#> [2,] 0 1
#> [3,] 1 0
#> [4,] 1 0
#> [5,] 0 1
#> [6,] 0 1
#> [7,] 0 1
#> [8,] 0 1
#> [9,] 0 1
#> [10,] 0 1
#> [11,] 1 0
#> [12,] 0 1
#> [13,] 0 1
#> [14,] 0 1
#> [15,] 0 1
#> [16,] 0 1
#> [17,] 0 1
#> [18,] 0 1
#> [19,] 1 0
#> [20,] 0 1
#> [21,] 0 1
#> [22,] 0 1
#> [23,] 0 1
#> [24,] 1 0
#> [25,] 0 1
#> [26,] 1 0
#> [27,] 0 1
#> [28,] 0 1
#> [29,] 0 1
#> [30,] 0 1
#> [31,] 0 1
#> [32,] 0 1
#> [33,] 0 1
#> [34,] 0 1
#> [35,] 0 1
#> [36,] 1 0
#> [37,] 1 0
#> [38,] 1 0
#> [39,] 0 1
#> [40,] 1 0
#> [41,] 0 1
#> [42,] 0 1
#> [43,] 0 1
#> [44,] 1 0
#> [45,] 0 1
#> [46,] 0 1
#> [47,] 1 0
#> [48,] 0 1
#> [49,] 0 1
#> [50,] 0 1
#> [51,] 0 1
#> [52,] 0 1
#> [53,] 0 1
#> [54,] 0 1
#> [55,] 0 1
#> [56,] 1 0
#> [57,] 0 1
#> [58,] 0 1
#> [59,] 0 1
#> [60,] 0 1
#> [61,] 0 1
#> [62,] 1 0
#> [63,] 1 0
#> [64,] 0 1
#> [65,] 1 0
#> [66,] 1 0
#> [67,] 0 1
#> [68,] 0 1
#> [69,] 0 1
#> [70,] 0 1
#> [71,] 0 1
#> [72,] 0 1
#> [73,] 0 1
#> [74,] 0 1
#> [75,] 0 1
#> [76,] 0 1
#> [77,] 0 1
#> [78,] 0 1
#> [79,] 0 1
#> [80,] 0 1
#> [81,] 0 1
#> [82,] 0 1
#> [83,] 0 1
#> [84,] 0 1
#> [85,] 0 1
#> [86,] 0 1
#> [87,] 0 1
#> [88,] 0 1
#> [89,] 0 1
#> [90,] 1 0
#> [91,] 0 1
#> [92,] 0 1
#> [93,] 0 1
#> [94,] 0 1
#> [95,] 0 1
#> [96,] 1 0
#> [97,] 0 1
#> [98,] 1 0
#> [99,] 0 1
#> [100,] 1 0
#> [101,] 1 0
#> [102,] 0 1
#> [103,] 1 0
#> [104,] 0 1
#> [105,] 1 0
#> [106,] 0 1
#> [107,] 0 1
#> [108,] 1 0
#> [109,] 0 1
#> [110,] 1 0
#> [111,] 0 1
#> [112,] 0 1
#> [113,] 1 0
#> [114,] 0 1
#> [115,] 0 1
#> [116,] 0 1
#> [117,] 0 1
#> [118,] 1 0
#> [119,] 1 0
#> [120,] 0 1
#> [121,] 0 1
#> [122,] 0 1
#> [123,] 0 1
#> [124,] 0 1
#> [125,] 0 1
#> [126,] 0 1
#> [127,] 0 1
#> [128,] 1 0
#> [129,] 0 1
#> [130,] 0 1
#> [131,] 0 1
#> [132,] 0 1
#> [133,] 0 1
#> [134,] 1 0
#> [135,] 0 1
#> [136,] 1 0
#> [137,] 0 1
#> [138,] 0 1
#> [139,] 0 1
#> [140,] 0 1
#> [141,] 0 1
#> [142,] 1 0
#> [143,] 1 0
#> [144,] 0 1
#> [145,] 0 1
#> [146,] 0 1
#> [147,] 0 1
#> [148,] 0 1
#> [149,] 0 1
#> [150,] 0 1
#> [151,] 0 1
#> [152,] 0 1
#> [153,] 0 1
#> [154,] 1 0
#> [155,] 0 1
#> [156,] 1 0
#> [157,] 0 1
#> [158,] 0 1
#> [159,] 0 1
#> [160,] 0 1
#> [161,] 0 1
#> [162,] 0 1
#> [163,] 1 0
#> [164,] 0 1
#> [165,] 0 1
#> [166,] 0 1
#> [167,] 1 0
#> [168,] 0 1
#> [169,] 1 0
#> [170,] 0 1
#> [171,] 0 1
#> [172,] 1 0
#> [173,] 0 1
#> [174,] 1 0
#> [175,] 1 0
#> [176,] 0 1
#> [177,] 0 1
#> [178,] 0 1
#> [179,] 1 0
#> [180,] 0 1
#> [181,] 1 0
#> [182,] 1 0
#> [183,] 0 1
#> [184,] 0 1
#> [185,] 0 1
#> [186,] 1 0
#> [187,] 0 1
#> [188,] 1 0
#> [189,] 0 1
#> [190,] 0 1
#> [191,] 0 1
#> [192,] 1 0
#> [193,] 0 1
#> [194,] 0 1
#> [195,] 1 0
#> [196,] 0 1
#> [197,] 1 0
#> [198,] 0 1
#> [199,] 0 1
#> [200,] 0 1
#> [201,] 0 1
#> [202,] 0 1
#> [203,] 0 1
#> [204,] 0 1
#> [205,] 1 0
#> [206,] 0 1
#> [207,] 0 1
#> [208,] 0 1
#> [209,] 1 0
#> [210,] 0 1
#> [211,] 1 0
#> [212,] 1 0
#> [213,] 0 1
#> [214,] 0 1
#> [215,] 0 1
#> [216,] 0 1
#> [217,] 0 1
#> [218,] 0 1
#> [219,] 0 1
#> [220,] 1 0
#> [221,] 0 1
#> [222,] 0 1
#> [223,] 0 1
#> [224,] 0 1
#> [225,] 0 1
#> [226,] 0 1
#> [227,] 0 1
#> [228,] 0 1
#> [229,] 0 1
#> [230,] 0 1
#> [231,] 0 1
#> [232,] 0 1
#> [233,] 0 1
#> [234,] 1 0
#> [235,] 0 1
#> [236,] 0 1
#> [237,] 0 1
#> [238,] 0 1
#> [239,] 1 0
#> [240,] 0 1
#> [241,] 1 0
#> [242,] 0 1
#> [243,] 0 1
#> [244,] 0 1
#> [245,] 1 0
#> [246,] 0 1
#> [247,] 0 1
#> [248,] 0 1
#> [249,] 0 1
#> [250,] 0 1
#> [251,] 0 1
#> [252,] 1 0
#> [253,] 0 1
#> [254,] 0 1
#> [255,] 1 0
#> [256,] 1 0
#> [257,] 0 1
#> [258,] 0 1
#> [259,] 0 1
#> [260,] 0 1
#> [261,] 0 1
#> [262,] 0 1
#> [263,] 0 1
#> [264,] 1 0
#> [265,] 1 0
#> [266,] 1 0
#> [267,] 0 1
#> [268,] 0 1
#> [269,] 0 1
#> [270,] 0 1
#> [271,] 0 1
#> [272,] 0 1
#> [273,] 0 1
#> [274,] 1 0
#> [275,] 0 1
#> [276,] 0 1
#> [277,] 0 1
#> [278,] 0 1
#> [279,] 0 1
#> [280,] 0 1
#> [281,] 0 1
#> [282,] 1 0
#> [283,] 0 1
#> [284,] 0 1
#> [285,] 0 1
#> [286,] 0 1
#> [287,] 0 1
#> [288,] 0 1
#> [289,] 0 1
#> [290,] 0 1
#> [291,] 1 0
#> [292,] 0 1
#> [293,] 0 1
#> [294,] 0 1
#> [295,] 0 1
#> [296,] 0 1
#> [297,] 0 1
#> [298,] 0 1
#> [299,] 0 1
#> [300,] 0 1
#> [301,] 0 1
#> [302,] 1 0
#> [303,] 0 1
#> [304,] 0 1
#> [305,] 0 1
#> [306,] 0 1
#> [307,] 0 1
#> [308,] 0 1
#> [309,] 0 1
#> [310,] 0 1
#> [311,] 0 1
#> [312,] 0 1
#> [313,] 0 1
#> [314,] 0 1
#> [315,] 0 1
#> [316,] 0 1
#> [317,] 0 1
#> [318,] 0 1
#> [319,] 0 1
#> [320,] 0 1
#> [321,] 0 1
#> [322,] 1 0
#> [323,] 0 1
#> [324,] 0 1
#> [325,] 0 1
#> [326,] 0 1
#> [327,] 0 1
#> [328,] 1 0
#> [329,] 0 1
#> [330,] 0 1
#> [331,] 0 1
#> [332,] 0 1
#> [333,] 0 1
#> [334,] 0 1
#> [335,] 0 1
#> [336,] 0 1
#> [337,] 0 1
#> [338,] 0 1
#> [339,] 0 1
#> [340,] 0 1
#> [341,] 0 1
#> [342,] 0 1
#> [343,] 0 1
#> [344,] 1 0
#> [345,] 1 0
#> [346,] 0 1
#> [347,] 0 1
#> [348,] 1 0
#> [349,] 1 0
#> [350,] 0 1
#> [351,] 0 1
#> [352,] 0 1
#> [353,] 0 1
#> [354,] 0 1
#> [355,] 0 1
#> [356,] 1 0
#> [357,] 0 1
#> [358,] 0 1
#> [359,] 0 1
#> [360,] 0 1
#> [361,] 0 1
#> [362,] 0 1
#> [363,] 0 1
#> [364,] 0 1
#> [365,] 1 0
#> [366,] 0 1
#> [367,] 0 1
#> [368,] 0 1
#> [369,] 1 0
#> [370,] 0 1
#> [371,] 0 1
#> [372,] 0 1
#> [373,] 0 1
#> [374,] 0 1
#> [375,] 0 1
#> [376,] 0 1
#> [377,] 0 1
#> [378,] 1 0
#> [379,] 0 1
#> [380,] 0 1
#> [381,] 1 0
#> [382,] 1 0
#> [383,] 1 0
#> [384,] 0 1
#> [385,] 0 1
#> [386,] 1 0
#> [387,] 0 1
#> [388,] 0 1
#> [389,] 0 1
#> [390,] 0 1
#> [391,] 0 1
#> [392,] 0 1
#> [393,] 0 1
#> [394,] 0 1
#> [395,] 0 1
#> [396,] 1 0
#> [397,] 1 0
#> [398,] 0 1
#> [399,] 0 1
#> [400,] 0 1
#> [401,] 1 0
#>
#> $data
#> sex age_group smoking_status lung_disease exercise_freq bmi_category
#> 2 female 55+ former yes moderate normal
#> 4 male 18-34 current no low overweight
#> 5 female 35-54 former no moderate normal
#> 6 male 18-34 current no moderate overweight
#> 7 female 55+ never no low obese
#> 8 female 35-54 former no low obese
#> 9 male 55+ never no moderate overweight
#> 10 female 55+ current no moderate normal
#> 11 male 18-34 never no high overweight
#> 14 female 18-34 never no high overweight
#> 15 female 55+ former no high overweight
#> 16 male 55+ former no moderate overweight
#> 17 female 18-34 never no low normal
#> 18 male 35-54 former yes moderate normal
#> 19 female 55+ former yes low obese
#> 21 female 18-34 never no low obese
#> 23 male 35-54 current no moderate overweight
#> 24 male 35-54 former no moderate overweight
#> 25 male 35-54 never no low overweight
#> 26 female 55+ former no high normal
#> 27 male 35-54 current yes low normal
#> 28 male 55+ never no moderate normal
#> 29 female 55+ never no low obese
#> 30 female 18-34 former no high normal
#> 31 female 35-54 never no low overweight
#> 33 female 18-34 current yes high normal
#> 34 male 35-54 never no low obese
#> 35 male 18-34 former no high normal
#> 36 male 55+ never no low normal
#> 38 male 18-34 never no moderate normal
#> 39 female 35-54 former no moderate overweight
#> 40 male 35-54 former yes moderate overweight
#> 42 male 35-54 never no low normal
#> 43 male 18-34 never no low obese
#> 44 female 18-34 never no low obese
#> 45 male 18-34 never no moderate normal
#> 46 female 35-54 former no low normal
#> 47 female 35-54 never no moderate normal
#> 49 male 55+ former no moderate overweight
#> 50 male 18-34 never no high normal
#> 51 female 18-34 current no high normal
#> 52 male 35-54 former yes high normal
#> 53 female 35-54 never no moderate obese
#> 54 female 18-34 never no high obese
#> 55 male 55+ former no low obese
#> 56 male 55+ never yes moderate normal
#> 57 female 35-54 never no high normal
#> 59 female 35-54 never no low overweight
#> 60 female 55+ former no low normal
#> 62 female 18-34 never no moderate overweight
#> 63 female 35-54 never no moderate normal
#> 64 male 18-34 never no moderate obese
#> 65 female 55+ former no moderate underweight
#> 66 male 35-54 former yes high normal
#> 67 male 35-54 never no moderate obese
#> 68 male 18-34 never no moderate normal
#> 69 female 55+ former yes low overweight
#> 70 female 35-54 current no high normal
#> 71 male 35-54 current no low obese
#> 73 male 55+ former yes high normal
#> 76 male 35-54 never no high overweight
#> 77 female 18-34 current no moderate normal
#> 78 female 18-34 current no high overweight
#> 80 female 55+ never no low overweight
#> 82 female 18-34 never no moderate normal
#> 85 male 18-34 current no low normal
#> 86 female 18-34 current no low normal
#> 87 male 18-34 current no low normal
#> 88 female 35-54 current yes moderate normal
#> 89 female 55+ never no low obese
#> 90 male 35-54 current no low overweight
#> 91 male 55+ former yes moderate normal
#> 92 male 35-54 current no moderate normal
#> 93 male 35-54 never no low obese
#> 94 female 18-34 never no moderate overweight
#> 95 male 18-34 former no high overweight
#> 96 female 35-54 current yes high normal
#> 97 male 35-54 never no low obese
#> 99 male 55+ former no moderate normal
#> 101 female 35-54 current yes high normal
#> 102 male 18-34 never no low obese
#> 103 female 55+ former yes low overweight
#> 106 male 35-54 former no high overweight
#> 111 female 35-54 current no low obese
#> 114 female 18-34 current yes high overweight
#> 115 female 55+ former no moderate normal
#> 117 male 55+ former no low overweight
#> 118 female 35-54 current no high normal
#> 119 female 35-54 former no low overweight
#> 120 female 18-34 never no moderate overweight
#> 122 female 35-54 never no high normal
#> 124 female 55+ former no moderate normal
#> 127 male 35-54 current no high normal
#> 129 male 18-34 never no high normal
#> 130 male 18-34 never no low obese
#> 131 female 35-54 former no low normal
#> 132 female 35-54 former no low obese
#> 133 female 18-34 never no moderate overweight
#> 134 female 55+ former no moderate overweight
#> 135 male 18-34 current no moderate overweight
#> 136 male 35-54 never no low overweight
#> 137 male 18-34 never no high overweight
#> 139 female 35-54 never no moderate normal
#> 140 male 35-54 never no high underweight
#> 147 male 18-34 never no moderate normal
#> 148 female 18-34 never no high overweight
#> 150 female 18-34 current yes high normal
#> 151 female 18-34 never no moderate normal
#> 154 female 35-54 never no high overweight
#> 155 male 35-54 former yes low obese
#> 156 female 18-34 former no low obese
#> 157 female 55+ never no high obese
#> 160 female 18-34 never no high obese
#> 161 female 18-34 never no moderate overweight
#> 162 male 55+ never no low underweight
#> 163 male 18-34 current no low overweight
#> 166 male 55+ current no low normal
#> 167 female 18-34 former no high obese
#> 168 male 18-34 never no high normal
#> 169 male 55+ never no low overweight
#> 171 male 18-34 never no high overweight
#> 172 male 35-54 never no moderate overweight
#> 175 female 55+ never no low obese
#> 177 female 18-34 never no high normal
#> 178 female 18-34 never no moderate normal
#> 179 male 55+ former no low obese
#> 180 male 55+ current yes moderate obese
#> 181 female 18-34 never no moderate normal
#> 183 female 55+ former no low obese
#> 184 male 35-54 current yes moderate normal
#> 185 female 55+ never no low overweight
#> 186 male 35-54 never no moderate overweight
#> 187 male 35-54 current no moderate obese
#> 188 male 18-34 never no moderate obese
#> 189 male 55+ never no low obese
#> 190 female 35-54 former no low normal
#> 191 female 18-34 never no high normal
#> 192 female 18-34 never no low obese
#> 193 female 35-54 never no high normal
#> 194 female 35-54 former no low obese
#> 195 female 18-34 former no high overweight
#> 196 female 18-34 current no high normal
#> 197 female 35-54 current no moderate overweight
#> 198 female 35-54 never no low overweight
#> 199 male 18-34 never no moderate obese
#> 202 female 35-54 never no high normal
#> 205 male 18-34 never no low overweight
#> 206 female 18-34 current yes low normal
#> 207 male 35-54 never no moderate overweight
#> 208 female 18-34 never no moderate normal
#> 209 female 55+ former no low underweight
#> 210 male 35-54 former no moderate overweight
#> 211 male 35-54 never no high normal
#> 213 female 18-34 never no moderate obese
#> 214 female 18-34 never no low normal
#> 215 male 18-34 never no moderate normal
#> 216 female 18-34 never no high normal
#> 218 male 18-34 current no moderate normal
#> 219 female 55+ never no moderate normal
#> 221 female 55+ former no moderate overweight
#> 224 female 35-54 former no low normal
#> 225 female 55+ never no low normal
#> 226 male 35-54 never yes low normal
#> 229 female 55+ current no low normal
#> 230 female 35-54 never no low normal
#> 231 female 18-34 never no moderate obese
#> 232 female 18-34 current no high overweight
#> 233 male 35-54 never no low normal
#> 234 female 35-54 never no moderate overweight
#> 236 male 35-54 never no moderate overweight
#> 237 female 35-54 former no low overweight
#> 238 female 18-34 current no low normal
#> 240 male 18-34 current yes high overweight
#> 241 female 35-54 current no high obese
#> 242 female 35-54 never no moderate obese
#> 243 female 55+ former no low normal
#> 244 female 55+ never no low normal
#> 246 female 18-34 never no moderate overweight
#> 248 male 35-54 never no low obese
#> 249 female 55+ former no moderate overweight
#> 250 male 18-34 current yes high normal
#> 252 female 35-54 current no moderate overweight
#> 253 female 55+ never no moderate normal
#> 254 female 35-54 never no high normal
#> 255 female 35-54 current yes low normal
#> 256 female 18-34 former no high normal
#> 257 female 55+ current yes moderate overweight
#> 258 female 18-34 never no low obese
#> 260 female 55+ former no low normal
#> 261 female 55+ former no low normal
#> 263 male 55+ current no moderate normal
#> 264 male 35-54 former no high obese
#> 266 male 18-34 current no moderate normal
#> 267 female 35-54 former no low overweight
#> 268 female 18-34 never no moderate overweight
#> 269 male 55+ former no moderate normal
#> 270 male 35-54 never no high overweight
#> 271 female 55+ former no low overweight
#> 272 female 55+ current no low normal
#> 274 female 35-54 former no low obese
#> 278 female 35-54 former no moderate overweight
#> 279 female 18-34 never no low obese
#> 281 male 35-54 never no moderate overweight
#> 282 male 55+ never no high normal
#> 284 male 18-34 never no moderate obese
#> 285 female 18-34 current no moderate normal
#> 287 male 35-54 never no moderate normal
#> 290 female 18-34 never no low overweight
#> 291 male 35-54 former yes low obese
#> 292 male 18-34 current no low overweight
#> 294 male 55+ never no low overweight
#> 296 female 35-54 never no moderate normal
#> 297 male 18-34 former no high normal
#> 300 female 18-34 never no moderate overweight
#> 301 female 35-54 never no high obese
#> 302 male 18-34 never no high overweight
#> 304 male 18-34 never no moderate overweight
#> 305 male 35-54 current no moderate normal
#> 306 female 18-34 former no high normal
#> 307 male 35-54 former no high normal
#> 309 female 55+ current yes high overweight
#> 310 male 55+ never no high normal
#> 311 female 55+ former no moderate overweight
#> 312 female 35-54 never no high normal
#> 313 male 18-34 never no high normal
#> 314 female 35-54 never no moderate normal
#> 315 female 55+ never no low overweight
#> 316 female 18-34 former no moderate obese
#> 317 female 35-54 never no high overweight
#> 318 male 35-54 current no moderate obese
#> 319 male 55+ current yes moderate overweight
#> 320 female 35-54 former no low overweight
#> 322 male 55+ former no low obese
#> 323 female 18-34 never no low overweight
#> 324 male 35-54 current yes high normal
#> 326 female 18-34 never no high overweight
#> 331 female 18-34 never no high normal
#> 332 male 35-54 current no moderate normal
#> 333 male 18-34 never no moderate overweight
#> 335 female 55+ never no high obese
#> 336 male 35-54 current no low obese
#> 338 male 35-54 never no moderate normal
#> 339 male 35-54 never no moderate normal
#> 341 female 55+ former no low obese
#> 342 male 35-54 current no moderate obese
#> 343 male 18-34 current no high normal
#> 344 male 35-54 current no high obese
#> 346 female 35-54 former no low normal
#> 348 female 35-54 former no high obese
#> 349 male 18-34 never no high normal
#> 352 male 18-34 current no moderate overweight
#> 356 female 18-34 never no moderate obese
#> 357 male 35-54 former no moderate obese
#> 358 male 35-54 former no low overweight
#> 360 male 18-34 never no moderate overweight
#> 363 male 35-54 current no high normal
#> 365 male 35-54 never no low normal
#> 366 male 18-34 former no high overweight
#> 367 female 18-34 never no high obese
#> 368 male 18-34 former no high overweight
#> 370 male 35-54 current no moderate normal
#> 374 female 55+ current no moderate normal
#> 375 female 18-34 never no high normal
#> 376 male 18-34 former no moderate normal
#> 377 female 35-54 former yes high normal
#> 378 female 35-54 current yes low obese
#> 381 female 18-34 current no low obese
#> 382 female 55+ current no low overweight
#> 383 female 18-34 never no moderate overweight
#> 384 male 18-34 never no low normal
#> 385 male 18-34 former no moderate normal
#> 387 male 18-34 current no moderate obese
#> 390 female 18-34 former no moderate normal
#> 391 male 18-34 former no moderate obese
#> 392 female 18-34 never no low normal
#> 395 male 55+ current no low normal
#> 396 male 18-34 never no low normal
#> 397 male 35-54 never no low normal
#> 398 male 18-34 never no moderate overweight
#> 402 male 35-54 current no high overweight
#> 405 female 55+ current no low normal
#> 406 female 35-54 current yes moderate normal
#> 408 male 18-34 never no moderate normal
#> 411 female 35-54 current yes moderate overweight
#> 412 female 18-34 current yes high overweight
#> 414 female 35-54 former no high obese
#> 416 male 18-34 current no high normal
#> 418 female 18-34 never no high overweight
#> 419 male 35-54 current no low overweight
#> 420 female 18-34 current yes low obese
#> 421 female 18-34 never no low obese
#> 422 male 35-54 never no moderate overweight
#> 423 male 18-34 current no moderate overweight
#> 424 male 35-54 current no moderate normal
#> 426 male 35-54 current no moderate normal
#> 428 female 18-34 former yes moderate normal
#> 429 male 35-54 former no moderate overweight
#> 430 male 35-54 never no moderate overweight
#> 431 male 35-54 never no low overweight
#> 433 male 35-54 former no high underweight
#> 435 male 35-54 never no low obese
#> 437 female 18-34 never no low overweight
#> 438 male 35-54 former no low normal
#> 441 female 35-54 never no low obese
#> 445 male 35-54 former no low normal
#> 447 female 35-54 former no low obese
#> 448 female 55+ former no low overweight
#> 451 male 55+ current yes low overweight
#> 452 male 55+ former no low overweight
#> 453 female 35-54 never no low normal
#> 454 female 55+ never no moderate obese
#> 455 male 55+ former no moderate normal
#> 458 male 55+ never no low overweight
#> 462 female 55+ former yes moderate normal
#> 463 male 35-54 never no moderate normal
#> 464 female 35-54 never no moderate overweight
#> 466 female 55+ former no moderate normal
#> 467 female 18-34 current yes high normal
#> 469 female 18-34 never no moderate overweight
#> 470 female 55+ never yes low overweight
#> 471 male 55+ never no moderate overweight
#> 472 female 55+ former no high normal
#> 473 female 18-34 never no high overweight
#> 474 female 35-54 former no low underweight
#> 476 female 55+ former no low overweight
#> 479 female 18-34 never no high obese
#> 480 male 55+ current no low normal
#> 481 male 35-54 never no moderate underweight
#> 487 male 35-54 never yes low obese
#> 488 female 55+ former no high overweight
#> 490 female 18-34 never no low normal
#> 491 male 55+ current no low obese
#> 492 male 55+ former no low overweight
#> 494 male 18-34 never no high obese
#> 498 male 35-54 current no moderate obese
#> 500 male 18-34 former no low normal
#> 502 female 55+ current no low obese
#> 505 male 18-34 former no high overweight
#> 507 female 18-34 never no low overweight
#> 508 female 18-34 current no moderate obese
#> 509 male 18-34 never no low overweight
#> 510 male 35-54 never no high normal
#> 512 female 35-54 never no low obese
#> 514 male 35-54 never no low overweight
#> 515 female 55+ former no moderate overweight
#> 516 female 35-54 former yes moderate normal
#> 517 male 35-54 never no moderate overweight
#> 518 female 18-34 never no moderate normal
#> 520 male 18-34 never no low normal
#> 522 male 18-34 current yes high normal
#> 523 female 55+ former no moderate normal
#> 525 male 35-54 never no low overweight
#> 527 female 18-34 current no low normal
#> 528 male 18-34 current yes high normal
#> 529 female 35-54 former no high normal
#> 531 male 18-34 never no high normal
#> 533 female 18-34 former no low obese
#> 534 male 35-54 current yes high normal
#> 535 male 18-34 never no high overweight
#> 536 female 55+ current no low obese
#> 537 male 18-34 never no high normal
#> 538 female 35-54 never no moderate obese
#> 539 male 35-54 former yes moderate normal
#> 541 male 35-54 current yes moderate overweight
#> 542 male 18-34 never no high underweight
#> 544 male 55+ never no moderate overweight
#> 545 female 55+ former no moderate normal
#> 546 male 18-34 never no high overweight
#> 547 female 35-54 never no moderate normal
#> 548 female 18-34 current no high normal
#> 549 male 55+ current yes moderate overweight
#> 550 male 55+ former no high normal
#> 551 female 55+ current yes moderate normal
#> 553 female 35-54 never no moderate normal
#> 556 male 18-34 never no high underweight
#> 557 female 55+ never no low obese
#> 558 male 35-54 former no moderate normal
#> 559 female 35-54 never no moderate overweight
#> 560 male 18-34 never no high obese
#> 561 male 35-54 current yes low obese
#> 562 male 18-34 never no high normal
#> 563 male 55+ former yes low obese
#> 564 male 18-34 current no moderate normal
#> 567 male 35-54 former no low obese
#> 569 male 55+ never no high normal
#> 570 male 18-34 never no high normal
#> 571 female 18-34 current yes high overweight
#> 573 female 18-34 current no low overweight
#> 575 male 35-54 current yes low overweight
#> 578 female 35-54 former no high normal
#> 581 female 18-34 never no high obese
#> 584 female 35-54 current no low normal
#> 586 male 35-54 current yes moderate overweight
#> 587 female 18-34 never no high normal
#> 588 female 18-34 never no high normal
#> 590 male 35-54 never yes low obese
#> 591 male 35-54 never no high normal
#> 593 male 35-54 former no moderate obese
#> 594 male 35-54 current yes moderate normal
#> 595 female 55+ current no high normal
#> 600 male 18-34 never no moderate normal
#> diet_quality health_insurance
#> 2 fair no
#> 4 poor yes
#> 5 good no
#> 6 good no
#> 7 good yes
#> 8 good yes
#> 9 poor yes
#> 10 poor yes
#> 11 fair yes
#> 14 good yes
#> 15 fair no
#> 16 poor yes
#> 17 good yes
#> 18 fair yes
#> 19 fair yes
#> 21 good yes
#> 23 fair yes
#> 24 good yes
#> 25 fair no
#> 26 good yes
#> 27 good yes
#> 28 fair yes
#> 29 fair yes
#> 30 good no
#> 31 good yes
#> 33 poor no
#> 34 good yes
#> 35 fair yes
#> 36 good yes
#> 38 fair yes
#> 39 poor yes
#> 40 poor yes
#> 42 good yes
#> 43 fair yes
#> 44 poor yes
#> 45 poor no
#> 46 poor no
#> 47 poor no
#> 49 poor yes
#> 50 fair no
#> 51 poor yes
#> 52 good yes
#> 53 good yes
#> 54 fair no
#> 55 fair yes
#> 56 poor yes
#> 57 fair no
#> 59 good yes
#> 60 good yes
#> 62 poor yes
#> 63 fair yes
#> 64 poor yes
#> 65 fair yes
#> 66 fair yes
#> 67 poor yes
#> 68 poor no
#> 69 fair yes
#> 70 fair yes
#> 71 good yes
#> 73 good yes
#> 76 good yes
#> 77 fair no
#> 78 poor no
#> 80 poor yes
#> 82 good no
#> 85 poor no
#> 86 poor yes
#> 87 poor yes
#> 88 good yes
#> 89 good yes
#> 90 fair yes
#> 91 poor yes
#> 92 fair yes
#> 93 fair yes
#> 94 fair yes
#> 95 poor yes
#> 96 good yes
#> 97 fair yes
#> 99 poor yes
#> 101 poor yes
#> 102 poor yes
#> 103 good yes
#> 106 good yes
#> 111 poor yes
#> 114 fair yes
#> 115 poor yes
#> 117 good yes
#> 118 good yes
#> 119 good yes
#> 120 poor no
#> 122 good yes
#> 124 fair yes
#> 127 fair yes
#> 129 good yes
#> 130 good yes
#> 131 fair no
#> 132 poor yes
#> 133 fair no
#> 134 fair yes
#> 135 fair no
#> 136 poor no
#> 137 good yes
#> 139 fair no
#> 140 good yes
#> 147 poor no
#> 148 poor yes
#> 150 good yes
#> 151 fair no
#> 154 good yes
#> 155 fair no
#> 156 fair yes
#> 157 fair yes
#> 160 poor no
#> 161 good yes
#> 162 poor yes
#> 163 poor yes
#> 166 good yes
#> 167 poor no
#> 168 poor no
#> 169 poor yes
#> 171 good yes
#> 172 poor yes
#> 175 fair yes
#> 177 good yes
#> 178 fair yes
#> 179 poor yes
#> 180 poor yes
#> 181 good no
#> 183 fair yes
#> 184 fair yes
#> 185 poor yes
#> 186 fair yes
#> 187 fair yes
#> 188 fair no
#> 189 poor yes
#> 190 poor no
#> 191 fair yes
#> 192 fair yes
#> 193 good yes
#> 194 poor yes
#> 195 fair yes
#> 196 poor no
#> 197 good no
#> 198 poor yes
#> 199 fair yes
#> 202 good yes
#> 205 poor yes
#> 206 fair yes
#> 207 good yes
#> 208 good yes
#> 209 good yes
#> 210 poor yes
#> 211 good yes
#> 213 poor no
#> 214 good yes
#> 215 fair no
#> 216 poor yes
#> 218 good yes
#> 219 good yes
#> 221 poor yes
#> 224 good yes
#> 225 poor yes
#> 226 fair no
#> 229 good yes
#> 230 good yes
#> 231 fair yes
#> 232 poor no
#> 233 good yes
#> 234 good no
#> 236 fair yes
#> 237 poor yes
#> 238 fair no
#> 240 fair yes
#> 241 fair no
#> 242 poor no
#> 243 good yes
#> 244 fair yes
#> 246 poor yes
#> 248 poor no
#> 249 fair yes
#> 250 good no
#> 252 good no
#> 253 fair yes
#> 254 poor yes
#> 255 good yes
#> 256 good no
#> 257 good yes
#> 258 poor no
#> 260 poor yes
#> 261 fair yes
#> 263 fair yes
#> 264 poor no
#> 266 fair yes
#> 267 poor yes
#> 268 fair no
#> 269 good yes
#> 270 fair no
#> 271 poor yes
#> 272 poor yes
#> 274 fair yes
#> 278 poor yes
#> 279 good yes
#> 281 poor yes
#> 282 poor yes
#> 284 poor no
#> 285 good yes
#> 287 fair yes
#> 290 good yes
#> 291 good no
#> 292 poor yes
#> 294 poor no
#> 296 poor no
#> 297 good yes
#> 300 poor yes
#> 301 good yes
#> 302 poor yes
#> 304 good yes
#> 305 fair yes
#> 306 good yes
#> 307 good no
#> 309 poor yes
#> 310 good yes
#> 311 fair yes
#> 312 fair yes
#> 313 good yes
#> 314 poor yes
#> 315 fair yes
#> 316 poor yes
#> 317 good yes
#> 318 fair yes
#> 319 fair yes
#> 320 good yes
#> 322 good yes
#> 323 poor no
#> 324 good yes
#> 326 fair yes
#> 331 good yes
#> 332 fair yes
#> 333 good no
#> 335 fair yes
#> 336 fair no
#> 338 fair yes
#> 339 fair yes
#> 341 fair yes
#> 342 good no
#> 343 good yes
#> 344 poor yes
#> 346 fair yes
#> 348 good yes
#> 349 fair yes
#> 352 fair yes
#> 356 good no
#> 357 good yes
#> 358 fair yes
#> 360 good no
#> 363 fair no
#> 365 good yes
#> 366 good yes
#> 367 poor yes
#> 368 poor yes
#> 370 good yes
#> 374 good yes
#> 375 poor yes
#> 376 good no
#> 377 good no
#> 378 fair no
#> 381 poor yes
#> 382 good yes
#> 383 fair yes
#> 384 poor yes
#> 385 fair yes
#> 387 fair yes
#> 390 poor yes
#> 391 poor no
#> 392 good yes
#> 395 poor yes
#> 396 poor yes
#> 397 fair yes
#> 398 fair yes
#> 402 fair yes
#> 405 good yes
#> 406 good no
#> 408 poor yes
#> 411 fair yes
#> 412 good yes
#> 414 fair yes
#> 416 good yes
#> 418 fair yes
#> 419 fair yes
#> 420 poor yes
#> 421 poor no
#> 422 good yes
#> 423 fair yes
#> 424 fair yes
#> 426 fair yes
#> 428 good yes
#> 429 fair yes
#> 430 good yes
#> 431 poor yes
#> 433 fair yes
#> 435 fair yes
#> 437 fair no
#> 438 good yes
#> 441 fair yes
#> 445 good yes
#> 447 fair yes
#> 448 fair yes
#> 451 fair yes
#> 452 fair yes
#> 453 good yes
#> 454 fair yes
#> 455 poor yes
#> 458 good yes
#> 462 fair yes
#> 463 good yes
#> 464 fair yes
#> 466 fair yes
#> 467 poor yes
#> 469 fair yes
#> 470 good yes
#> 471 good yes
#> 472 fair no
#> 473 good yes
#> 474 fair yes
#> 476 good yes
#> 479 good yes
#> 480 poor yes
#> 481 good no
#> 487 poor yes
#> 488 poor yes
#> 490 fair yes
#> 491 poor yes
#> 492 poor yes
#> 494 poor yes
#> 498 poor yes
#> 500 fair yes
#> 502 poor yes
#> 505 fair yes
#> 507 poor yes
#> 508 fair yes
#> 509 good yes
#> 510 good yes
#> 512 poor yes
#> 514 fair no
#> 515 poor no
#> 516 good yes
#> 517 poor yes
#> 518 fair no
#> 520 poor no
#> 522 fair yes
#> 523 fair yes
#> 525 poor yes
#> 527 poor yes
#> 528 good yes
#> 529 good yes
#> 531 fair no
#> 533 poor yes
#> 534 good yes
#> 535 fair yes
#> 536 good yes
#> 537 good yes
#> 538 fair yes
#> 539 good yes
#> 541 fair yes
#> 542 good no
#> 544 fair yes
#> 545 good yes
#> 546 fair yes
#> 547 poor no
#> 548 poor yes
#> 549 good yes
#> 550 fair yes
#> 551 fair yes
#> 553 good yes
#> 556 fair yes
#> 557 fair yes
#> 558 fair yes
#> 559 fair no
#> 560 fair yes
#> 561 poor yes
#> 562 good no
#> 563 poor no
#> 564 good no
#> 567 good yes
#> 569 good yes
#> 570 poor no
#> 571 good yes
#> 573 fair yes
#> 575 poor yes
#> 578 fair yes
#> 581 poor yes
#> 584 good yes
#> 586 good yes
#> 587 good yes
#> 588 poor yes
#> 590 poor no
#> 591 fair no
#> 593 poor yes
#> 594 fair yes
#> 595 poor yes
#> 600 poor no
#>
#> $method
#> [1] "cramers_v"
#>
#> $alpha
#> [1] NA
#>
#> $membership
#> sex=female sex=male age_group=18-34
#> 1 2 3
#> age_group=35-54 age_group=55+ smoking_status=never
#> 2 1 3
#> smoking_status=former smoking_status=current lung_disease=no
#> 1 4 3
#> lung_disease=yes exercise_freq=low exercise_freq=moderate
#> 4 1 5
#> exercise_freq=high bmi_category=underweight bmi_category=normal
#> 6 7 6
#> bmi_category=overweight bmi_category=obese diet_quality=poor
#> 8 1 1
#> diet_quality=fair diet_quality=good health_insurance=no
#> 5 6 3
#> health_insurance=yes
#> 1
#>
#> attr(,"class")
#> [1] "catmodgraph"The pruned, clustered modality network is our primary object of
interest. Plot it with signed = TRUE to reveal the
direction of association encoded in the stored standardised Pearson
residuals:
plot(mg, color_by = "cluster", signed = TRUE)
Green edges indicate modalities that co-occur more than expected under independence (attraction); red edges indicate co-occurrence below expectation (repulsion). Communities that mix green and red edges are showing modalities that cluster by the magnitude of their chi-square signal, which can conflate opposing substantive patterns — a known limitation of unsigned Louvain on a phi-weighted graph.
Summarise the community composition:
comm <- summarise_modality_communities(mg)
comm$community_summary
#> community n_modalities n_variables
#> 1 1 7 7
#> 2 2 2 2
#> 3 3 4 4
#> 4 4 2 2
#> 5 5 2 2
#> 6 6 3 3
#> 7 7 1 1
#> 8 8 1 1
#> variables
#> 1 age_group, bmi_category, diet_quality, exercise_freq, health_insurance, sex, smoking_status
#> 2 age_group, sex
#> 3 age_group, health_insurance, lung_disease, smoking_status
#> 4 lung_disease, smoking_status
#> 5 diet_quality, exercise_freq
#> 6 bmi_category, diet_quality, exercise_freq
#> 7 bmi_category
#> 8 bmi_category
#> mean_internal_weight
#> 1 0.1638083
#> 2 0.1191307
#> 3 0.2087700
#> 4 0.3262129
#> 5 0.1265974
#> 6 0.1429239
#> 7 NA
#> 8 NACommunities here should be interpreted as groups of co-associated modalities. They are not respondent segments and they are not a low-dimensional embedding.
Method 2 — Multiple Correspondence Analysis (MCA)
MCA is the classical geometric approach to categorical multivariate structure. It projects both rows (respondents) and columns (modalities) onto a shared low-dimensional Euclidean space where proximity reflects association strength.
library(FactoMineR)
library(factoextra)
mca_df <- stats::na.omit(survey_health)
mca_df[] <- lapply(mca_df, function(x) if (is.factor(x)) x else as.factor(x))
mca_res <- MCA(mca_df, graph = FALSE)
fviz_mca_var(
mca_res, repel = TRUE,
col.var = "contrib",
gradient.cols = c("#AFA9EC", "#7F77DD", "#534AB7"),
ggtheme = ggplot2::theme_minimal(base_size = 10),
title = "MCA biplot: modality map (first two dimensions)"
)
What the MCA biplot shows, that the modality graph does not:
- Continuous geometry. Two modalities plotted far from the origin on the same axis are strongly associated with that axis, which summarises the dominant pattern of variation in the data. Modalities near the origin are “average” — they don’t load heavily on any dimension.
-
Contribution colour scale. The
contribcolouring shows how much each modality contributes to the first two MCA dimensions; a bright modality is driving the overall structure, a pale one is passive. - Row-column duality. MCA would also place respondents on the same map (not shown above), enabling direct respondent–modality comparison in a single coordinate system.
What the MCA biplot does not show, that the modality graph does:
- Discrete edges with a significance filter. MCA gives every modality a coordinate regardless of whether its associations with other modalities are statistically significant.
-
Community structure with an algorithmic cluster
assignment. MCA produces a geometry; communities must be
imposed on top via
FactoMineR::HCPC()or similar. - Signed pairwise information. MCA coordinates encode a complex blend of many associations; you cannot read “these two modalities attract, those two repel” off the biplot directly.
Bottom line: MCA is the right tool if you want a low-dimensional continuous map of both respondents and categories. The modality graph is the right tool if you want a discrete, filtered, pairwise picture with explicit communities.
Method 3 — Bipartite respondent–modality network
The bipartite graph preserves the raw incidence structure: respondents on one side, modalities on the other, an edge whenever a respondent endorses a modality. Nothing is filtered or projected.
bg <- bipartite_modality_graph(survey_health)
bg
#> catbipartite object (respondent-modality incidence graph)
#> Respondent nodes : 401
#> Modality nodes : 22
#> Edges : 3208
#> Variables : sex, age_group, smoking_status, lung_disease, exercise_freq, bmi_category, diet_quality, health_insurance
plot(bg, max_respondents = 150)
The bipartite view is honest about what categorical survey data actually is: a set of respondents and a set of modalities they endorsed. Every other method in this vignette is derived from this bipartite structure via some kind of projection or statistical filter.
When to use the bipartite graph directly:
- Affiliation-network analysis (persons to events, authors to papers, species to sites) — where the bipartite structure is the scientific object, not a scaffolding for something else.
- Auditing or diagnostic work — seeing which respondents endorse which modalities without any modelling assumption.
When not to use it directly:
- For substantive interpretation of modality relationships. Without projection and filtering, the bipartite view is too granular to summarise category-level structure.
Method 4 — Naive co-occurrence projection
Projecting the bipartite graph onto its modality partition yields a count-based co-occurrence network. Every pair of modalities gets an edge weighted by the number of respondents who endorsed both.
proj <- igraph::bipartite_projection(bg$graph, which = "true")
proj
#> IGRAPH 90b5d24 UNW- 22 208 --
#> + attr: name (v/c), weight (e/n)
#> + edges from 90b5d24 (vertex names):
#> [1] sex=female--age_group=55+ sex=female--smoking_status=former
#> [3] sex=female--lung_disease=yes sex=female--exercise_freq=moderate
#> [5] sex=female--bmi_category=normal sex=female--diet_quality=fair
#> [7] sex=female--health_insurance=no sex=female--age_group=35-54
#> [9] sex=female--lung_disease=no sex=female--diet_quality=good
#> [11] sex=female--smoking_status=never sex=female--exercise_freq=low
#> [13] sex=female--bmi_category=obese sex=female--health_insurance=yes
#> [15] sex=female--smoking_status=current sex=female--diet_quality=poor
#> + ... omitted several edgesPlot only the strongest 40% of projected edges, to keep the figure readable:
w_proj <- igraph::E(proj)$weight
q60 <- stats::quantile(w_proj, 0.60, na.rm = TRUE)
proj_strong <- igraph::delete_edges(proj, which(w_proj < q60))
proj_strong <- igraph::delete_vertices(
proj_strong, which(igraph::degree(proj_strong) == 0)
)
mod_var <- sub("=.*", "", igraph::V(proj_strong)$name)
pal <- grDevices::hcl.colors(length(unique(mod_var)), palette = "Dark 3")
v_col <- pal[as.integer(factor(mod_var))]
op <- graphics::par(mar = c(1, 1, 3, 1))
plot(
proj_strong,
layout = igraph::layout_with_fr(proj_strong),
vertex.size = 10,
vertex.color = v_col,
vertex.label.cex = 0.65,
vertex.label.color = "#2C2C2A",
edge.width = 0.3,
edge.color = grDevices::adjustcolor("grey40", alpha.f = 0.3),
main = "Naive co-occurrence projection (top 40% edges)"
)
graphics::par(op)This is the key comparison with the catgraph modality
network. Both are modality-only graphs. Both have edges between
modalities. But they are weighted differently:
- Co-occurrence projection: edge weight = raw count of shared respondents. High-frequency modalities appear central because they are endorsed by many respondents, not because they are substantively associated with their neighbours.
-
catgraphmodality network: edge weight = phi on the 2×2 indicator table, after chi-square significance filtering. Adjusts for base rates — a high-frequency modality only gets a strong edge to a neighbour if their co-occurrence exceeds what their marginal frequencies would predict under independence.
The difference matters. If you are comparing populations (e.g. two
countries or two ecological sites), raw co-occurrence will always
emphasise whatever modalities are most common in each population, which
can obscure substantive structural differences. catgraph is
designed to filter out base-rate effects so you see the signal.
Summary table: when to use what
| Question you have | Method |
|---|---|
| Which category levels significantly co-associate across variables? | catgraph modality network |
| What is the low-dimensional geometry of my categories? |
MCA (FactoMineR::MCA) |
| Who endorsed what, unfiltered? |
Bipartite graph
(bipartite_modality_graph) |
| Which modalities are most often endorsed together, raw? | Co-occurrence projection |
| Are two groups jointly balanced on their categorical structure? |
joint_balance() (see next
section) |
| Who are my respondent segments? |
poLCA, FactoMineR::HCPC()
|
| Do my variables show conditional-independence structure? |
bnlearn, gRim, or GGM packages |
What catgraph adds
-
Statistical filtering native to nominal data.
Unlike MCA (which embeds everything) or co-occurrence projection (which
filters only by count),
catgraphuses chi-square significance plus Bergsma- corrected effect sizes to decide which associations are substantive. - Explicit communities with a clustering algorithm. Louvain (or walktrap) on the phi-weighted graph gives discrete community assignments that MCA does not provide without an additional hierarchical-clustering step.
-
Signed interpretation via stored residuals. The
std_residedge attribute retains the direction of association, which is lost in both MCA coordinates and unsigned co-occurrence counts. -
A shared framework for variable-level and modality-level
analysis.
catgraphandbuild_modality_graphproduce objects with consistent conventions (pruning, community detection, visualisation), making it natural to move between the two layers. -
A cross-group diagnostic workflow.
joint_balance()uses the modality-graph machinery to assess whether two or more subgroups share the same joint categorical structure, which no purely geometric or purely count-based method does directly.
Where catgraph should not be overclaimed
- It is not a respondent-segmentation tool.
Communities are groups of modalities, not groups of respondents. Use
poLCAorFactoMineR::HCPC()for segmentation. - It is not an MCA replacement. If you want a geometry, use MCA.
- It is not a conditional-independence model. Edges encode marginal pairwise dependence only. Use graphical models for conditional structure.
- Its unsigned phi weights can mix attraction with repulsion in the
same community. Interpret cluster structure alongside the signed
residual view (
signed = TRUEinplot.catmodgraph).
Joint balance diagnostics for grouped categorical data
The problem
Suppose you are combining two samples — two survey waves, two study sites, two arms of a meta-analysis, or two levels of a sociodemographic stratum. Standard practice is to report a “Table 1”: percentages of each categorical variable broken down by group, with a chi-square test per variable, so the reader can see whether the groups are comparable.
This is a marginal check. It asks, for each variable separately: is the distribution of that variable the same across groups? It does not ask whether the joint distribution is the same. Two groups can pass every marginal check and still differ in joint structure — for example, if the association between education and political orientation has one sign in one group and the opposite sign in another, the marginal distributions of education and of political orientation can be identical across groups while the joint distribution differs substantially. A marginal-only diagnostic misses this.
For meta-analysis, repeated cross-sectional surveys, and multi-site observational studies, this is not an abstract concern. It is the reason heterogeneity is often diagnosed by marginal indicators, pooled by simple weighting, and only later found to have been driven by differences in the joint covariate structure that the marginal-check step could not detect.
The diagnostic
joint_balance() is a complete three-step diagnostic for
this situation. It takes a categorical data frame plus a grouping
variable and runs:
Marginal tests. A chi-square test per variable, with Benjamini-Hochberg adjustment across variables. This is the classical Table 1 check, reported for continuity with prior practice.
Pairwise omnibus tests. For each pair of groups, the permutation test from
test_modality_graph_equality()is run on the modality-level association network. This tests whether the full joint categorical structure is the same across the pair. Bonferroni adjustment is applied across the group pairs.Edge-wise post-hoc tests. For each group pair whose omnibus test rejects,
test_modality_edge_differences()identifies which specific modality-pair associations drive the difference, with Benjamini-Hochberg adjustment across edges within the pair.
The three steps have three separate multiple-testing families. This is deliberate: they answer three different questions and should not be bundled into a single correction.
data(survey_health)
jb <- joint_balance(
survey_health,
group = "sex",
n_perm = 500,
n_perm_edge = 500,
seed = 1
)
jb
summary(jb)
plot(jb)The print() method gives a three-block summary: how many
marginal variables rejected, how many group pairs rejected, and within
each rejecting pair how many edges differ significantly. The
plot() method produces a two-panel diagnostic: a bar chart
of adjusted marginal p-values on the left, and the modality-difference
graph for the most-rejecting pair on the right.
The chunk above is set eval = FALSE because a
500-permutation run inflates vignette build time noticeably; the output
is identical in form to the print methods shown in the function’s
?joint_balance examples.
When to use this instead of the alternatives
joint_balance() is not the only way to check cross-group
comparability of categorical data. Three established alternatives are
worth naming explicitly, because each is the better tool for part of
this space.
Log-linear homogeneity-of-association tests
The textbook tool for “does the A–B association differ across groups?” is the log-linear model of the three-way table, with a likelihood-ratio test of the no-three-way-interaction null (Agresti, Categorical Data Analysis, chapter 9). For a single pair of variables this is more powerful than the permutation test used here, more interpretable because the model gives log-odds-ratio differences with standard errors, and exact under large-sample theory.
Use the log-linear approach when: you have a specific two-variable association hypothesis to test; the three-way table is well-populated (no sparse cells); the cross-group comparison is the primary scientific question and the analysis is confirmatory.
Use joint_balance() when: you have many
variables (say, more than four), the log-linear model would require
specifying and comparing a combinatorially large set of interaction
terms; the analysis is exploratory, diagnostic, or descriptive; the
purpose is to decide whether the groups are comparable enough to pool,
rather than to characterise the specific form of any difference.
These are complementary roles. A reasonable workflow uses
joint_balance() as a first-pass screen, then fits a
log-linear model to any specific association the edge-wise step flags as
differing.
Multiple Correspondence Analysis with supplementary group
MCA with the grouping variable as a supplementary categorical
projects the groups onto the modality coordinate space, so the reader
can see whether groups occupy distinguishable regions of the joint
category geometry (see Greenacre & Blasius, Multiple
Correspondence Analysis and Related Methods, 2006; implemented as
FactoMineR::MCA(..., quali.sup = ...)).
Use MCA when: the goal is a global visual summary of the category space with the groups located within it; the dimensionality of the joint structure is itself of interest; you are presenting a single low-dimensional figure to describe between-group differences.
Use joint_balance() when: the goal is a
pass/fail comparability verdict with edge-level localisation, rather
than a low-dimensional representation; you want a formal p-value rather
than a visual judgement; the reader needs to know which
specific modality pairs differ, not just that the groups land in
different regions of a projection.
Again, these compose. The MCA plot is often the right figure to
accompany a significant joint_balance() result, with the
MCA showing the overall geometric separation and the
plot_modality_difference() graph showing the edges
responsible.
tableone and cobalt
For the marginal Table 1 itself,
tableone::CreateTableOne() and
cobalt::bal.tab() are more mature than the marginal panel
of joint_balance(). They handle continuous covariates
(which joint_balance() explicitly does not), report
standardised mean differences, and produce publication-ready formatting.
The marginal step in joint_balance() exists only so the
reader can see the marginal and joint views side-by-side; it is not
intended to replace these established tools.
The recommended pattern is to use
tableone or cobalt for the formal Table 1 in
the paper, and joint_balance() for the joint-structure
diagnostic, citing both. The joint step is stronger than the marginal
step (joint balance implies marginal balance) but the marginal step is
stronger on continuous variables and on reporting conventions.
What joint balance does not do
Three limitations to state plainly, because reviewers will ask.
It is not a causal adjustment tool. Rejecting the joint omnibus means the groups differ in joint categorical structure; it does not say whether that difference confounds the outcome of interest. Propensity-score weighting, entropy balancing, and matching are separate methodologies and remain necessary when the question is causal.
It is descriptive, not model-based. The edge weights are bivariate phi coefficients, not conditional log-odds-ratios from a fitted model. If you need confidence intervals on specific three-way interaction terms, fit the log-linear model. The permutation test gives an honest p-value for “does the overall joint structure differ?” but the answer is global, not parametric.
It does not handle repeated measures. The permutation null assumes exchangeable rows under group relabelling. This is satisfied by independent cross-sections (different respondents at each wave) but violated by panel data (same respondents followed over time). For repeated-measures comparisons, the permutation machinery here is not the right tool; standard longitudinal categorical methods (GEE with a working independence structure, mixed-effects log-linear models) are.
A worked example: conditional modality graphs
The comparison above is unconditional — every row of each group is used. Sometimes the scientifically interesting question is conditional: not “does the joint structure differ between two groups?” but “within one subgroup, how does the association structure vary across a secondary stratum?”.
build_conditional_modality_graph() is a thin wrapper
around build_modality_graph() that subsets the data by one
or more conditioning levels and records the conditioning on the returned
object. The output is a plain catmodgraph and composes with
all existing methods.
data(survey_health)
# Within one age stratum, compare across levels of a second variable
ag_levels <- levels(survey_health$age_group)
subset_by_age <- lapply(
ag_levels,
function(ag) {
build_conditional_modality_graph(
survey_health,
given = list(age_group = ag)
)
}
)
names(subset_by_age) <- ag_levels
compare_modality_graphs(
subset_by_age,
restrict = "common",
signed = TRUE
)The conditioning specification is stored in
mg$conditioning$given and can be inspected if you need to
audit what a given panel represents. Note that the function is designed
for conditioning on observed stratification variables only;
conditioning on a cluster membership that was itself estimated from the
association structure reintroduces circularity, and the function does
not support it (the 0.6.0 release notes document this refocus in
detail).
References
- Agresti, A. (2013). Categorical Data Analysis (3rd ed.). Wiley.
- Greenacre, M. (2017). Correspondence Analysis in Practice (3rd ed.). Chapman and Hall/CRC.
- Greenacre, M., & Blasius, J. (Eds.) (2006). Multiple Correspondence Analysis and Related Methods. Chapman and Hall/CRC.
- Borgatti, S. P., & Everett, M. G. (1997). Network analysis of 2-mode data. Social Networks, 19(3), 243–269.
- Latapy, M., Magnien, C., & Del Vecchio, N. (2008). Basic notions for the analysis of large two-mode networks. Social Networks, 30(1), 31–48.
- Vermunt, J. K., & Magidson, J. (2002). Latent class cluster analysis. In J. A. Hagenaars & A. L. McCutcheon (Eds.), Applied Latent Class Analysis. Cambridge University Press.
